HTP SuperStor Contender SSC-50SB Installation & Operation Manual

Superstor contender solar supplement sb series and se series
Hide thumbs
Table of Contents

Advertisement

Quick Links

SuperStor Contender
Solar Supplement
INSTALLATION
OPERATION
MAINTENANCE

TROUBLESHOOTING

SB Series* Models
SE Series** Models
SSC-50SB / SSC-80SB
SSC-50SE / SSC-80SE
SSC-119SB
SSC-119SE
*With back-up heat exchanger
**With back-up electric element
*NOTE: SB Series Model Shown in Drawing
The solar energy system described in this manual, when properly installed and maintained, meets the minimum standards
established by the SRCC. This certification does not imply endorsement or warranty of this product by the SRCC.
NOTICE: HTP reserves the right to make product changes or updates without notice and will not be held liable for typographical errors
in literature.
The surfaces of these products contacted by consumable water contain less than 0.25% lead by weight, as required by the Safe
Drinking Water Act, Section 1417.
NOTE TO CONSUMER: PLEASE KEEP ALL INSTRUCTIONS FOR FUTURE REFERENCE.
120 Braley Rd. P.O. Box 429
East Freetown, MA 02717-0429
www.htproducts.com
LP-200 REV. 1.6.15
