Ozito SGP-300 Instruction Manual

400w
Hide thumbs Also See for SGP-300:
Table of Contents

Advertisement

Quick Links

SPRAY
GUN
400W
INSTRUCTION MANUAL
SPECIFICATIONS
Voltage:
230-240V ~ 50Hz
Power:
400W
Max. Flow Rate:
450ml/min
Viscosity:
20 - 80 secsonds
Less than 30 DIN-S
Pot Capacity:
800ml
Nozzle:
ø2.5mm
Weight (tool only):
1.5kg
ozito.com.au
1
WHAT'S IN THE BOX

Spray Gun

Viscosity Cup
Cleaning Needle
SGP-300

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SGP-300 and is the answer not in the manual?

Questions and answers

Related Manuals for Ozito SGP-300

Summary of Contents for Ozito SGP-300

  • Page 1: Spray Gun

    Spray Gun 400W INSTRUCTION MANUAL SPECIFICATIONS Voltage: 230-240V ~ 50Hz Power: 400W Max. Flow Rate: 450ml/min Viscosity: 20 - 80 secsonds Viscosity Cup Less than 30 DIN-S Pot Capacity: 800ml Nozzle: ø2.5mm Weight (tool only): 1.5kg ozito.com.au Cleaning Needle SGP-300...

  • Page 2: Know Your Product

    KNOW YOUR PRODUCT SETUP & PREPARATION 1. ASSEMBLY SPRAY GUN 1 Air Cap 5 Spray Regulator Dial WARNING! ENSURE THE TOOL IS DISCONNECTED FROM 2 Nozzle 6 Soft Grip Handle THE POWER SUPPLY BEFORE PERFORMING ANY OF THE 3 On/Off Trigger 7 Quick Release Dial FOLLOWING OPERATIONS.

  • Page 3: Operation

    OPERATION 3. CONTROLS 2. PREPARATION CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, NOTE: FOR BEST RESULTS, SURFACE PREPARATION AND PAINT A RESIDUAL CURRENT DEVICE (RATED 30MA OR LESS) THINNING ARE THE TWO MOST IMPORTANT AREAS. ENSURE MUST BE USED. ALL SURFACES ARE FREE OF DUST, DIRT AND GREASE.
  • Page 4 2cm to achieve an even maintaining a distance of roughly 20cm from the workpiece. the workpiece while coat. maintaining distance and Be sure to keep the spray gun at a perpendicular angle. angle to the piece. SGP-300...

  • Page 5: Maintenance

    Recycling packaging reduces the need for landfill and raw materials. Note: Ozito Industries will not be responsible for any damage or injuries Reuse of recycled material decreases pollution in the environment. caused by the repair of the sander by an unauthorised person or by mishandling Please recycle packaging where facilities exist.
  • Page 6 16 17 18 19 How To Order Available spare parts can be ordered through the Special Orders Desk at any Bunnings Warehouse. If you have any further questions, please contact Ozito Customer Service on: Australia: 1800 069 486 New Zealand: 0508 069 486...

  • Page 7: Electrical Safety

    Replace the extension lead if damaged or defective. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire and electric shock.

  • Page 8: Warranty

    • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0915...
