AIRLESS PAINT
SPRAYER
650W
INSTRUCTION MANUAL
SPECIFICATIONS
Input Power:
650W
Voltage:
230-240V ~ 50Hz
Max. Pressure:
3000psi (21MPa)
Max. Flow Rate:
1.09±10% l/min
Spray Tip Size:
515
Outlet Paint Connector: 1/4-18NPSM
Max. Hose Pressure:
12000psi (83MPa)
High Pressure Hose:
7.6m
Full-load Current:
2.0~3.1A
Short Circuit Rating:
5kA
Paint Temperature:
5-40°C
Weight:
7.69kg
ozito.com.au
1
WHAT'S IN THE BOX
Airless Sprayer
Spray Gun
High Pressure Hose
ASG-6000
Advertisement
Table of Contents
Related Manuals for Ozito ASG-6000
Summary of Contents for Ozito ASG-6000
- Page 1 3000psi (21MPa) Max. Flow Rate: 1.09±10% l/min Spray Tip Size: Outlet Paint Connector: 1/4-18NPSM Spray Gun Max. Hose Pressure: 12000psi (83MPa) High Pressure Hose: 7.6m Full-load Current: 2.0~3.1A Short Circuit Rating: Paint Temperature: 5-40°C Weight: 7.69kg ozito.com.au High Pressure Hose ASG-6000...
- Page 2 KNOW YOUR PRODUCT SETUP & PREPARATION AIRLESS SPRAY GUN 1. ASSEMBLY 1 Pressure Control Dial 6 Inlet Hose 2 Stand 7 Pressure Release Lever Frame Connection 3 Return Pipe 8 On/Off Switch 4 Paint Outlet 9 Carry Handle 1. Remove four bolts from 5 Filter frame.
- Page 3 2. ASSEMBLY CONT. 3. PREPARATION Hose Connection This tool is recommended for the use with a residual current device with a rated residual current of 30mA or less. 1. Connect high pressure 2. Connect other end of hose hose to paint outlet and to gun swivel and tighten.
- Page 4 OPERATION 5. SPRAYING PROCEDURE 4. TEST SETTINGS Note: Do not thin paint for use in this spray gun. Note: Ensure the Airless Sprayer has been properly bled before comencing spraying procedure. Setting Pressure 1. Stand 30cm from area to 2. Turn the Airless Sprayer on. 1.
- Page 5 2. Only apply one coat at a time, always allow a coat to completely dry before adding another coat. 3. A void stopping and starting as this can lead to a patchy finish, It is best to start spraying outside the surface to be sprayed and avoid stopping in the middle of the surface, continue just past the opposite edge. ASG-6000...
- Page 6 CLEANING PROCEDURE CONT. CLEANING PROCEDURE Inlet Hose Caution: It is crucial to perform the pressure release procedure before starting the cleaning procedure. Follow this procedure diligently as a build-up of dried paint on the operating components can stop the unit 2. P ull the filter out of hose 1.
- Page 7 Bunnings Warehouse. For further information, or any parts not listed here, visit Working Position Prime Position www.ozito.com.au or contact Ozito Customer Service: Australia 1800 069 486 4. Squeeze trigger to release any remaining pressure in gun. New Zealand 0508 069 486...
- Page 8 Tool: 650W Airless Paint Sprayer SPARE PARTS Model No. ASG-6000 77 76 75 74 Accessories The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Description Part No. Item No.
- Page 9 The electric motor has been designed for 230V and 240V only. Always check that the power supply Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the corresponds to the voltage on the rating plate. extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged or defective. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire and electric shock.
- Page 10 • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0712...
