  • Page 1 Handbook EAP740 Enterprise Access Point...

  • Page 2: Copyright Notice

    4IPNET, INC. You may not alter or remove any copyright or other notice from copies of the content. All other brand and product names are claimed or registered marks of their respective companies or organizations.

  • Page 3: Fcc Caution

    FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 42cm between the radiator & your body. Copyright © 4IPNET, INC. All rights reserved.
  • Page 4  This declaration is only valid for configurations (combinations of software, firmware, and hardware) provided and supported by 4ipnet Inc. The use of software or firmware not provided and supported by 4ipnet Inc. may result in the equipment no longer being compliant with the regulatory requirements.
  • Page 5 Taiwan NCC Statement 根據 NCC 低功率電波輻射性電機管理辦法 規定: 第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、 加大功率或變更原設計之特性及功能。 第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即 停用，並改善至無干擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通 信。低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 在 5.25 ~ 5.35 秭赫頻帶內操作之無線資訊傳輸設備，限於室內使用。 For UNII 產品 (5GHz WLAN/WIFI) [警語內容] 使用此產品時應避免影響附近雷達系統之操作。 MPE [警語] 「電磁波曝露量 MPE 標準值 1mW/cm2，本產品使用時建議應距離人體 42 cm」 減少電磁波影響，請妥適使用 Copyright © 4IPNET, INC. All rights reserved.

  • Page 6: Package Contents

    EAP740 Enterprise Access Point ENGLISH Preface Package Contents 4ipnet EAP740 is a high-end, dual radio 802.11 1. 4ipnet EAP740 x 1 b/g/n + ac (Wave 2) MIMO Access Point (AP) with 2. Handbook x 1 the best performance for business and industrial 3.

  • Page 7: System Overview

    Handbook EAP740 Enterprise Access Point ENGLISH System Overview EAP740 Front View EAP740 Side View EAP740 Side View Copyright © 4IPNET, INC. All rights reserved.
  • Page 8 Handbook EAP740 Enterprise Access Point ENGLISH EAP740 status. The Status LED will start blinking when the restart/reset button Power LED is pressed. For the first 5 seconds, the LED will blink slowly (restart), and after 5 seconds, the LED will start blinking quickly (reset).

  • Page 9: Hardware Installation

    (a) Mounting on a Wall 1. Set two screws in the wall 128 mm (5.0 in.) apart. 2. Slide EAP740’s wall mounting slots down onto the screws so that the unit is secure. (b) Mounting on a Ceiling T-Bar 1. Use the included screws to attach two ceiling-mount T-bar clips to the back of EAP740.
  • Page 10 2. Connect EAP740 to your network device. Connect one end of the Ethernet cable to the Uplink (PoE) port of EAP740 and the other end of the cable to a switch, a router, or a hub. EAP740 is then connected to your existing wired LAN network.

  • Page 11: Getting Started

    1. To access the Web Management Interface, connect the administrator PC to the Uplink port of EAP740 via an Ethernet cable. Then, set a static IP address on the same subnet mask as EAP740 in TCP/IP of your PC, such as the following example: IP Address: 192.168.1.100...
  • Page 12 Handbook EAP740 Enterprise Access Point ENGLISH 4. After a successful login to EAP740, a System Overview page of the Web Management Interface will appear, as depicted below. The Web Management Interface - System Overview Page 5. To logout, simply click on the Logout button at the upper right hand corner of the interface to return to the Administrator Login Page.

  • Page 13: Common Settings

     Click on the Utilities icon on the main menu, and select the Change Password tab.  Enter a new password with a length of up to 32 characters, and retype it in the Re-enter New Password field.  Click SAVE to save the changes. Copyright © 4IPNET, INC. All rights reserved.
  • Page 14  Determine the Band, Protocol and Channel settings: Select your preferred Band, Protocol and Channel for you wireless connection. For example, select 2.4GHz for the band, 802.11g+802.11n for the protocol and 6 for the channel. Copyright © 4IPNET, INC. All rights reserved.
  • Page 15 (b) Enable a specific VAP from the drop-down menu of Profile Name and configure related settings below.  Check VAP status： After finishing VAP configuration, the status of enabled Virtual APs shall be reflected on the VAP Overview page. Copyright © 4IPNET, INC. All rights reserved.
  • Page 16 Handbook EAP740 Enterprise Access Point ENGLISH Virtual AP Overview Page Copyright © 4IPNET, INC. All rights reserved.
  • Page 17 ENGLISH Step 4. Configure WDS (Wireless Distribution System) Settings (Optional) To extend the wireless coverage, EAP740 supports WDS links on each RF card for connecting wirelessly to other WDS-capable APs (peer APs). By default, all WDS profiles are disabled.  Click on the Wireless button on the main menu.
  • Page 18 Congratulations! Now, 4ipnet EAP740 is installed and configured successfully. After EAP740's network configuration is completed, please remember to change the IP Address of your PC Connection Properties back to its original settings in order to ensure that your PC functions properly in its real network environments.
