  • Page 1 Keysight N2893A 100 MHz Current Probe User’s Guide...
  • Page 2 FAR and the DFARS and are set to the user. forth specifically in writing elsewhere in the EULA. Keysight shall be under no obligation to update, revise or otherwise modify the Software. With respect to any technical data N2893A 100 MHz Current Probe User’s Guide...
  • Page 3: Table Of Contents

    Procedure / 17 Characteristics and Specifications / 21 Plots / 24 Product Markings and Labels / 26 Service Strategy / 27 To return the Probe to Keysight Technologies for Service / 27 Index N2893A 100 MHz Current Probe User’s Guide...
  • Page 4 Contents N2893A 100 MHz Current Probe User’s Guide...
  • Page 5: Introduction

    Keysight N2893A 100 MHz Current Probe User’s Guide Introduction The N2893A is a wide-band, DC to 100 MHz, active current probe. The probe features low noise and low circuit insertion loss. The probe has the following operating regions that provide a wide, flat frequency response.
  • Page 6: Inspecting The Probe

    - If the shipping container is damaged, or the cushioning materials show signs of stress, notify the carrier as well as your Keysight Technologies Sales Office. Keep the shipping materials for the carrier’s inspection. The Keysight Technologies office will arrange for repair or replacement at Keysight Technologies’...
  • Page 7: Safety Information

    Do not install substitute parts or perform any unauthorized modification to the instrument. Only WARNING Keysight service centers should perform repair/maintenance on the equipment. To avoid short circuits and accidents that could result in injury or death, use the N2893A probe only DANGER with insulated power lines carrying 300V or less.
  • Page 8 (mains) power cord. The mains plug shall only be inserted in a socket outlet provided with a protective earth contact. You must not negate the protective action by using an extension cord (power cable) without a protective conductor (grounding). N2893A 100 MHz Current Probe User’s Guide...
  • Page 9: N2893A Components

    Always carry out demagnetizing before measurement. The probe should be connected to the oscilloscope for the demagnetizing process. This process takes about one second. During demagnetizing, a demagnetizing waveform is output. Refer to “Demagnetization and Zero Offset" on page 14 N2893A 100 MHz Current Probe User’s Guide...
  • Page 10 The probe output sensitivity 0.1 V/A will be automatically selected, as the probe is N OT E plugged into the AutoProbe interface. With a different output sensitivity, accurate measurements are not possible. N2893A 100 MHz Current Probe User’s Guide...
  • Page 11: Using The Probe

    When the probe is connected to a scope channel, the AutoProbe interface recognizes the N OT E probe as an N2893A and automatically configures several settings on the channel to which the probe is connected. N2893A 100 MHz Current Probe User’s Guide...
  • Page 12: Obtaining The Best Measurement Accuracy

    - The current direction indicator on the sensor aligns with actual current direction in the insulated conductor. - The sensor opening lever is in the Locked position and the sensor head is properly closed. N2893A 100 MHz Current Probe User’s Guide...
  • Page 13 When performing continuous measurements, it is necessary to be aware that the zero N OTE offset voltage will drift if the ambient temperature changes. At some frequencies, some sound may be produced by resonance. This has no effect N OT E on measurements. N2893A 100 MHz Current Probe User’s Guide...
  • Page 14: Demagnetization And Zero Offset

    Press the scope’s channel button (1, 2, 3, or 4) for the channel you are using. Click the softkey (under the display) and then press the key to Probe automatically start the demagnetization and zero offset process. Follow the on-screen instructions. N2893A 100 MHz Current Probe User’s Guide...
  • Page 15: Protecting The Probe Against Damage Resulting From Excessive Input

    Figure 11 on page 24 to know about the maximum continuous input range for the N2893A probe. It is recommended not to exceed this range. Built-in Safety Function In the following situations, the generated heat activates a built-in safety function in WARNING the probe that blocks normal output to prevent probe damage resulting from heating.
  • Page 16 Quit the measurement and cycle the power of the oscilloscope, if the shutdown occurs. The typical probe current consumption from the AutoProbe interface is shown in Figure Figure 6 Typical Probe Consumption N2893A 100 MHz Current Probe User’s Guide...
  • Page 17: Performance Verification For N2893A

    N2893A Probe Performance Verification for N2893A Use the following procedure to test the warranted Accuracy specifications for the N2893A probe (as listed on page 21). The recommended test interval to warrant performance of this probe is once a year. However, you can also test the probe’s performance as and when required using the recommended test equipment and by following the procedure documented in this chapter.
  • Page 18 Connect the test setup as shown in Figure 8 on page 19 as per the following substeps. a Clamp the N2893A probe around the test cable <1> and lock the sensor head of the probe. b Press the DEMAG button on the probe.
  • Page 19 N1022B adapter’s output using the NMD 3.5mm (M) to 3.5mm (F) adapter and 3.5mm (M) to BNC (F) adapter. b DMM <2> using a BNC (F)-to-banana adapter. This completes the test setup. N2893A 100 MHz Current Probe User’s Guide...
  • Page 20 DMM <2>. Calculate gain as follows: Gain = Gain should be between 0.99 and 1.01 (+/-1% gain accuracy). Remove the test cable and AC current generator from the N2893A probe. N2893A 100 MHz Current Probe User’s Guide...
  • Page 21: Characteristics And Specifications

    Requires 1MΩ termination. Valid for 23°C ±3°C (73°F ±5°F), at least 30 minutes after power on. b This is a specification and is guaranteed at 23°C ±3°C (73°F ±5°F). c Rise time is calculated as: Tr = 0.35/Bandwidth. N2893A 100 MHz Current Probe User’s Guide...
  • Page 22 6.89 in. x 0.71 in. x 1.6 in. Dimensions (Terminator) 28 mm x 81 mm x 24 mm 1.1 in. x 3.2 in. x 0.94 in Weight 210 g (7.4 oz.) Accessories Supplied Storage case, calibration certificate N2893A 100 MHz Current Probe User’s Guide...
  • Page 23 Item Characteristics Indoor Operating Temperature Range 0°C to 40°C (32°F to 104°F) Storage Temperature Range –10°C to 50°C (14°F to 122°F) Maximum Relative Humidity 80% (no condensation) (Operating or Storage) Maximum Altitude 2000m N2893A 100 MHz Current Probe User’s Guide...
  • Page 24: Plots

    N2893A Probe Plots Figure 10 Frequency Response of N2893A Figure 11 Continuous Maximum Input Rating of N2893A N2893A 100 MHz Current Probe User’s Guide...
  • Page 25 N2893A Probe Figure 12 Insert Impedance of N2893A Figure 13 Amplitude Accuracy Characteristic of N2893A N2893A 100 MHz Current Probe User’s Guide...
  • Page 26: Product Markings And Labels

    Indicates DC (Direct Current) or AC (Alternating Current). Indicates a risk of Electric Shock. Refer to the manual for more information. Earth terminal symbol: Used to indicate a circuit common connected to grounded chassis. N2893A 100 MHz Current Probe User’s Guide...
  • Page 27: Service Strategy

    N2893A Probe Service Strategy For calibration testing, return the N2893A probe to a Keysight Service Center. If the probe is under warranty, normal warranty services apply. If the probe is not under warranty, repair costs will be applied. To return the Probe to Keysight Technologies for Service...
  • Page 28 N2893A Probe N2893A 100 MHz Current Probe User’s Guide...
  • Page 29 IEC 61010-1 Safety Standards, sensor cable length, impedance, insertion, sensor head, insertion impedance, service, inspection, storage temperature range, instrument markings, ISM1-A, temperature coefficient, temperature range, labels, use, maximum altitude, using, maximum cable diameter, maximum circuit voltage, N2893A 100 MHz Current Probe User’s Guide...
  • Page 30 Index N2893A 100 MHz Current Probe User’s Guide...
