NOTICE
© 2017 SeaStar Solutions
A.3 Actuator – Dimensions
This drawing is NOT a template. It is for informational purposes only.
SCALE = 1:3.
4x ø0.30"
(8 mm)
8x ø0.30"
(8 mm)
0.8" (20 mm)
Figure A-3. Acuator – Mounting dimensions. NOT A TEMPLATE..
i7700 Installation Supplement, Rev. B
12.2" (310 mm)
11" (280 mm)
CLEARANCE FOR COVER REMOVAL
12" (304 mm)
11" (280 mm)
A-3
