• Open the HyperTerminal application (located in your Windows Accessories program
group) and connect a DB9-to-DB9 cable between your host PC and console port P2 of
the development board. Set the communication settings in HyperTerminal to 57600
baud, 8 bits, no parity and one stop bit. These settings are also noted in the
file.
• Click the
Go
HyperTerminal should display the
If the demo code still does not run, contact Zilog Technical Support at support.zilog.com.
QS005506-0111
Z8 Encore! XP F042A 8-Pin Development Kit
button. The Red and Yellow LEDs should blink in sequence.
LED Lights...
Quick Start Guide
message.
main.c
