- Page 1 Assembly Instruction 2 PERSON ASSEMBLY 4655 bestchoiceproducts P1/11...
- Page 2 1 x1PC 2 x1PC 3 x1PC 4 x1PC 5 x1PC 6 x1PC 7 x1PC 8 x2PCS 9 x1PC 10 x2PCS 11 x1PC 12 x1PC 13 x2PCS 14 x2PCS 15 x2PCS 16 x2PCS M7x48mm M6x40mm M6x35mm M4x20mm M4x35mm Ax6PCS Bx6PCS Cx10PCS Dx2PCS Ex8PCS 15x12mm...
- Page 3 Step 1 Attach part 8 frame sides to part 10 lower frame pieces with four part B screws Step 2 P3/11...
- Page 4 Step 3 Attach part L slider rails to part 5,6,and 7 frame pieces.Attach frame pieces to part 3 lower shelf with six part G dowels and six part A screws. Step 4 Slide in part 4 back. P4/11...
- Page 5 Step 5 Attach part 2 middle shelf with six part G dowels, six part H cam bolts, and six part I cam locks. Step 6 Attach drawer/shelf assembly to lower frame with six part C screws. P5/11...
- Page 6 Step 7 Attach part 9 middle support with two part B screws. Step 8 Attach part 1 tabletop with four part C screws. P6/11...
- Page 7 Step 9 Attach parts 13 and 14 drawer sides to drawer front panel with four part H cam bolts and four part cam locks. Repeat on other drawer front panel. Step 10 Slide in part 15 drawer backs. P7/11...
- Page 8 Step 11 Attach part 16 drawer back panel with four part E screws. Repeat on other drawer. Step 12 Attach two part K slider rails with tow part F screws on each. Attach part J knob with part D screw.Repeat on other drawer. P8/11...
- Page 9 Step 13 Slide in two drawers. If the drawers are not aligned or overlap each other, then unscrew runner’s screws slightly, re-adjust the drawers so they are fully aligned and levelled,then fully screw in the runner’s screws. Step 14 If the power socket is not use. Please plug up it with the parts P.
- Page 10 Go to Next track, Go to Previous track, Increase Volume. Decrease Volume. Power On/Off,Bluetooth disconnect, play/pause the music. Status Light Aux in The socket The USB output LED Touch ON: Push and hold "POWER" button for 3 seconds. The status light will turn blue and you will OFF: When playing music,push and hold "POWER"...
- Page 11 § 15.19 Labelling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
