- Page 1 INSTRUCTION MANUAL Macrame Hanging Chair Hardware SKY4578 + SKY5066 + SKY5905 Ver. 1...
- Page 2 NOTICE Retain these Important Safety Instructions for future reference. • It is the responsibility of the owner to ensure that all users of this product are adequately informed of all warnings and precautions. • Use this product only as instructed in this manual. •...
- Page 3 PRODUCT ASSEMBLY (CONCRETE) Place the part A anchor plate on your desired mounting position, then mark the four holes with a pencil. Use a power drill equipped with a concrete bit to drive four pilot holes. NOTE: Wear protective eyewear while drilling to prevent irritation from fallen debris.
- Page 4 PRODUCT ASSEMBLY (CONCRETE) Remove the washers and nut from the part B expansion bolt sets, then remove the bolt from the anchor sleeve. Replace the washer and nut on the bolt so the nut abuts the bolt head, followed by the spring washer and the flat washer. Return the bolt assembly to the anchor sleeve so the slits on the sleeve sit opposite to the bolt head.
- Page 5 PRODUCT ASSEMBLY (WOOD) Place the part A anchor plate on your Use a power drill to drive four pilot holes. desired mounting position, then mark the NOTE: Wear protective eyewear while four holes with a pencil. drilling to prevent irritation from fallen debris.
- Page 6 MOUNTING CHAIN POSITIONS (OPTION 1) Place one part D carabiner onto the ring Overlap the mounting rings on the of the part A anchor plate, then attach macrame chair and secure to the the part E mounting chain. lower carabiner. Connect a second part D carabiner to the link in the part E chain you want the chair to hang from.
- Page 7 MOUNTING CHAIN POSITIONS (OPTION 2) Place one part D carabiner on either end Connect the mounting rings on the of the part E chain. macrame chair to the part D carabiners. Loop the chain through the ring on the part A anchor plate.
- Page 8 HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
