- Page 1 INSTRUCTION MANUAL 5-Piece Wood Dining Set SKY4278 Ver. 1...
- Page 2 NOTICE Please retain these instructions for future reference. • Firmly secure all bolts, screws, and knobs before use. • Reconfirm that all bolts, screws, and knobs are secure every 90 days. • Do not use or store this item in the proximity of open flame or flammable/combustible chemicals. •...
- Page 3 PARTS RIGHT FRAME LEFT FRAME SEAT TOP SLAT 4 PCS 4 PCS 4 PCS 4 PCS MIDDLE SLAT BOTTOM SLAT FRONT FRAME MIDDLE SUPPORT 8 PCS 4 PCS 4 PCS 4 PCS TABLETOP 1 PC 4 PCS Pg. 3...
- Page 4 PRODUCT ASSEMBLY Please retain these instructions for future reference. Insert eighteen part 2 dowels into the part D top slat, part E middle slats, part F bottom slat, and part G front frame, four dowels on each. Pg. 4...
- Page 5 PRODUCT ASSEMBLY Arrange the slats/front frame between the part A right frame and part B left frame, making sure to insert the dowels into their corresponding holes on the frames Secure the slats/front frame with six part 1 hex screws, three hex screws on each side. Attach the part H middle support with two part 1 hex screws, one on each side.
- Page 6 PRODUCT ASSEMBLY Attach the part C seat with four part 3 screws. Repeat steps 1 to 3 to build three additional chairs. Pg. 6...
- Page 7 PRODUCT ASSEMBLY Insert a part 5 barrel nut into a part J leg. Screw two part 4 bolts into the barrel nut. Repeat on the other three legs. Attach the legs to the part I tabletop with eight part 6 washers and eight part 7 nuts, two washers/nuts per leg.
- Page 8 ASSEMBLY IS COMPLETE! PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included. All returned items will receive a full refund back to the original payment method.
