- Page 1 INSTRUCTION MANUAL Racing Style O ce Chair with Footrest SKY4792 + SKY4793 + SKY4794 + SKY4795 + SKY5056 + SKY5079 Ver. 1...
- Page 2 NOTICE Please retain these instructions for future reference. • Please do not exceed the weight limitations of this item. • Do not stand on or use any part of this product as a step ladder. • Firmly secure all bolts, screws and knobs before use. •...
- Page 3 PARTS BACKREST GAS LIFT COVER SEAT 1 PC 1 PC 1 PC ADJUSTMENT HINGE COVER (L/R) ARMREST (L/R) MECHANISM 1 PC 1 SET 1 SET BRACKET FOOTREST 1 PC 2 PCS Pg. 3...
- Page 4 PRODUCT ASSEMBLY Please retain these instructions for future reference. Insert five part B casters into the part A base. Insert the part C gas lift into the base, then place the part D gas lift cover. Pg. 4...
- Page 5 PRODUCT ASSEMBLY Remove the four screws from the part F seat. Flip up the hinges, then replace the screws to attach the seat to the part E backrest. Attach the part G hinge cover set with two part 1 screws. Pg.
- Page 6 PRODUCT ASSEMBLY Remove and replace eight screws under the seat to attach the part H armrest set and part I adjustment mechanism. Remove and replace four screws to attach two part J brackets. Slide the part K footrest into the brackets, then secure the ends with two part 2 rubber bands.
- Page 7 PRODUCT ASSEMBLY Use two hands to press the chair onto the assembled base/gas lift. Note: Make sure to apply even pressure when combining the chair and base. Pg. 7...
- Page 8 ASSEMBLY COMPLETE! Pull out and flip up the footrest to use it. PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
