- Page 1 INSTRUCTION MANUAL Bathroom Floor Cabinet with Drawer SKY4283 Ver. 2...
- Page 2 As shoppers, we’re always trying to find the perfect balance between quality & value. At BCP, we believe we’ve achieved that. Our diverse catalog of everyday essentials is tailored especially to our customers & guaranteed to hit that sweet spot of high quality & low price.
-
Page 3: Tools Required
NOTICE • Please do not exceed the weight limitations of this item. • Do not stand on or use any part of this product as a step ladder. • Firmly secure all bolts, screws and knobs before use. • Reconfirm that all bolts, screws, and knobs are secure every 90 days. •... - Page 4 HARDWARE DRAWER M4 X 12MM M4 X 30MM WALL ANCHOR STOPPER SCREW SCREW 1 PCS 1 PC 1 PC 1 PC FASTENER M4 X 15MM SCREW 1 PC 6 PCS PARTS TOP PANEL LEFT PANEL RIGHT PANEL BOTTOM PLATFORM 1 PC 1 PC 1 PC 1 PC...
- Page 5 PARTS RAILING DRAWER DRAWER DRAWER LEFT BOTTOM FRONT 2 PCS 1 PC 1 PC 1 PC DRAWER DRAWER BACK DOOR RIGHT 1 PC 1 PC 1 PC TIGHTENING CAMLOCKS Screw cam bolt Insert cam bolt and cam lock into Screw cam lock in completely.
-
Page 6: Product Assembly
PRODUCT ASSEMBLY Screw four part 1 cam bolts into the part A top panel. Attach part 17 fastener with a part 14 screw. Attach part E stopper bar with two part 12 screws. Attach part 13 drawer stopper with part 4 screw. - Page 7 PRODUCT ASSEMBLY Attach a part I railing to part B left panel with three part 18 screws. Screw in a part 1 cam bolt. Attach a part I railing to part C right panel with three part 18 screws. Screw in a part 1 cam bolt. Attach part 7 magnetic catch with two part 4 screws.
- Page 8 PRODUCT ASSEMBLY Attach part F drawer support to part B left panel and part C right panel with two part 3 dowels and two part 2 cam locks. Screw four part 1 cam bolts into the part D bottom platform...
- Page 9 PRODUCT ASSEMBLY Attach part D bottom platform to left/right panels four part 2 cam locks. Slide in the part H back panel. Attach part A top panel with four part 2 cam locks.
- Page 10 PRODUCT ASSEMBLY Screw four part 1 cam bolts into part K drawer front. Attach part 5 knob with a part 6 screw. Attach part L drawer left and part M drawer right to part N drawer back with four part 11 screws. Slide in the part J drawer bottom.
- Page 11 PRODUCT ASSEMBLY Slide the drawer onto the railings. Attach two part 9 hinges to part O door with four part 4 screws. Attach part 8 metal plate with two part 4 screws. Attach part 5 knob with a part 6 screw.
- Page 12 PRODUCT ASSEMBLY Attach the hinges on the part O door with four part 4 screws.
- Page 13 PRODUCT ASSEMBLY Insert four part 10 shelf pegs. Place part G shelf on the pegs.
- Page 14 PRODUCT ASSEMBLY If desired, secure the part 17 fastener to the wall with a part 16 wall anchor and part 15 screw.
- Page 15 Earn points while you shop. Join today! Give your friends 15% o their first order! For each successful referral you’ll receive 100 points. bestchoiceproducts.com...
-
Page 16: Help Center
HELP CENTER HELP CENTER Question about your product? We're here to help. Visit us at: Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com help.bestchoiceproducts.com CHAT CHAT Product Assembly Product Assembly Returns & Refunds Returns & Refunds PRODUCT WARRANTY INFORMATION PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long...
