- Page 1 INSTRUCTION MANUAL 2-Piece L-Shaped Sectional w/ Ottoman SKY4553 + SKY4554 Ver. 3...
- Page 2 Hardware & parts are located in the compartment underneath the sofa. Make sure to remove all items before assembly. bestchoiceproducts.com...
- Page 3 NOTICE Please retain these instructions for future reference. • Please do not exceed the weight limitations of this item. • Do not stand on or jump on any part of this item. • Firmly secure all bolts and knobs before use. •...
- Page 4 PARTS OTTOMAN SEAT CUSHION 2 PCS 12 PCS 1 PC Hidden under compartment. Parts and/or hardware located underneath this ottoman. BACK CUSHION OTTOMAN CUSHION LONG CUSHION 1 PC 1 PC 3 PCS Hidden under compartment. PRODUCT ASSEMBLY Remove the parts and hardware from the compartment underneath the furniture. Use your hand to screw eight part 1 bolts into two part C armrests, four bolts per armrest.
- Page 5 PRODUCT ASSEMBLY From within the compartment, attach an armrest to the part A sofa with four part 2 washers and four part 3 nuts. Screw in four part D legs. From within the compartment, attach an armrest to the part B lounger with four part 2 washers and four part 3 nuts.
- Page 6 PRODUCT ASSEMBLY Attach the sofa to the lounger with four part 1 bolts, eight part 2 washers, and eight part 3 nuts. NOTE: Each bolt is secured with two washers and two nuts, a washer/nut on each side. Flip up the backrest on the sofa and lounger. Place two part F seat cushions, a part G long cushion, and three part H back cushions.
- Page 7 PRODUCT ASSEMBLY Screw four part D legs into the part E ottoman. Place the part I ottoman cushion. ARRANGEMENT OPTIONS You can rearrange the sectional and cushions according to your preference.
- Page 8 HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
