- Page 1 INSTRUCTION MANUAL Modern Co ee Table with Lift-Top SKY2788 + SKY3688 + SKY4744 + SKY6257 Ver. 5...
-
Page 2: Tools Required
NOTICE The following safety hazards may result in serious injury or death: 1 PERSON APPROXIMATELY • Firmly secure all bolts, screws and knobs before use. ASSEMBLY 45 MIN. 100 LBS 1 PERSON UP TO 45 MIN. • Reconfirm that all bolts, screws, and knobs are secure 45LY ASSEMBLY ASSEMBLY... - Page 3 PARTS TABLETOP END PANEL DIVIDER 1 PC 1 PC 2 PCS SIDE PANEL INNER SHELF BOTTOM SHELF 2 PCS 1 PC 1 PC BASEBOARD LEG I LEG II 2 PCS 2 PCS 2 PCS LIFT HINGE I LIFT HINGE II END PANEL II 1 PC 1 PC...
- Page 4 TOOLS REQUIRED PRODUCT ASSEMBLY Please retain these instructions for future reference. Insert four part B cam bolts into each part 2 and part 12 end panel. Insert two part B cam bolts into each part 4 side panel.
- Page 5 TOOLS REQUIRED PRODUCT ASSEMBLY Insert four part B cam bolts into part 5 inner shelf. Insert five part B cam bolts and one part I footer into each part 8 and 9 legs. Use a hammer to secure the footer.
- Page 6 TOOLS REQUIRED PRODUCT ASSEMBLY Insert four part A dowels and four part C cam locks into each part 2 and part 12 end panel. Attach part 8 and 9 table legs to part 2 and part 12 end panels. Use a screwdriver to turn the cam lock to secure the cam bolt.
- Page 7 TOOLS REQUIRED PRODUCT ASSEMBLY Insert four part A dowels into part 6 bottom shelf. Use drill to attach part 7 baseboards to part 6 bottom shelf with four part F screws. Insert four part A dowels and four part C cam locks into each part 3 end dividers.
- Page 8 TOOLS REQUIRED PRODUCT ASSEMBLY Have the long size of the shelf vertically. Insert four part A dowels and four part C cam locks into part 5 inner shelf. Attach two part 4 side panels into part 5 inner shelf. Use a screwdriver to turn the cam lock to secure the cam bolt.
- Page 9 TOOLS REQUIRED PRODUCT ASSEMBLY Insert four part A dowels and ten part C cam locks into each sides of the shelf. Attach part 2 and part 12 end panels to each sides of the shelf. Use a screwdriver to turn the cam lock to secure the cam bolt.
- Page 10 TOOLS REQUIRED PRODUCT ASSEMBLY Have the co ee table standing on it’s legs. Peel and place part E tabletop pads on the tops of each part 8 and 9 legs. Then apply part D cam covers over each exposed cam lock.
- Page 11 TOOLS REQUIRED PRODUCT ASSEMBLY Use drill to attach part 1 tabletop to part 2 and part 12 endpanels with sixteen part F screws. Screw back the nuts from each lift hinges with the provided wrench.
- Page 12 HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
