- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Fusion Ceiling Mount Offset Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description FMSCAO...
-
Page 2: Important Safety Instructions
--SAVE THESE INSTRUCTIONS-- ACCESSORY: AN ACCESSORY is the secondary Chief product which is attached to a primary Chief product, and may have a component attached or setting on it. COMPONENT: A COMPONENT is an audiovisual item designed to be attached or resting on an accessory or mounting system such as a video camera, CPU, screen, display, projector, etc. - Page 3 Installation Instructions FMSCAO DIMENSIONS DIMENSIONS: INCHES [MILLIMETERS]...
-
Page 4: Installation Instructions
FMSCAO Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación... -
Page 5: Tools Required For Installation
Installation Instructions FMSCAO TOOLS REQUIRED FOR INSTALLATION 1/2" 5/32" 1/2" 1/2" 7/32" (included) nut driver (included) PARTS A (1) [Array offset] B (4) C (8) 5/16-18 x 1/2" D (8) 5/16-18 x 1" 5/16" E (8) 5/16" G (1) F (1) 7/32"... -
Page 6: Installation
Fusion Modular Systems installation instructions. NOTE: The following procedure assumes that Chief ceiling plates (not included) and extension columns (not included) have been properly installed following instructions provided with ceiling plates and extension columns. - Page 7 If the column attached to the ceiling plate is a 1-1/2" NPT column, the Chief pin connection adapter accessory (not included) must first be installed following instructions included with the accessory. No adapter is necessary if attaching to a Chief pin Towards front connection extension column. (C) x 4...
- Page 8 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief, a products division of Asia Pacific A Office No. 918 on 9/F, Shatin Galleria Milestone AV Technologies 18-24 Shan Mei Street...
