CAVS IPS-11G Karaoke Station
User's Manual
This product supports external memory devices with USB connectivity - USB flash drive,
USB hard drive, MP3 player, MP4 player, etc. with FAT32 file system (PC).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPS-11G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CAVS IPS-11G

Summary of Contents for CAVS IPS-11G

  • Page 1 All manuals and user guides at all-guides.com CAVS IPS-11G Karaoke Station User’s Manual This product supports external memory devices with USB connectivity - USB flash drive, USB hard drive, MP3 player, MP4 player, etc. with FAT32 file system (PC).
  • Page 2 All manuals and user guides at all-guides.com...

  • Page 3: Table Of Contents

    ---- Table of Contents ---- Introduction …………………………………………………………………………………………………….. 4 Safety and Warning Instruction ……………………………………………………………………………… 5 Specification……………………………………………………………………………………………………. 7 CAVS IPS-11G and Accessories ……………………………………………………………………………. 8 4.1 Package Contents………………………………………………………………………………… 4.2 Name of Each Part And Function Description ……………………………………………….. Installation and Connection ………………………………………………………………………………….. 5.1 Connecting USB Memory Device ……………………………………………………………….

  • Page 4: Introduction

    USB memory device, such as USB flash drive, USB hard drive, MP3 player, MP4 player, etc. It also plays the same USB hard drives as those made for CAVS DVD 105G and 203G USB players. CAVS IPS-11G is a mobile and versatile player for your home as well as professional entertainment.

  • Page 5: Safety And Warning Instruction

    All manuals and user guides at all-guides.com 2. Safety and Warning Instruction Please read it carefully to ensure safe and proper use:...
  • Page 6 All manuals and user guides at all-guides.com FCC NOTE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 7: Specification

    All manuals and user guides at all-guides.com 3. Specification...

  • Page 8: Cavs Ips-11G And Accessories

    All manuals and user guides at all-guides.com 4. CAVS IPS-11G Karaoke Station and Accessories. 4.1 Package Contents CAVS IPS-11G Karaoke Station · A/V cable · AC power adapter · Remote control & Battery · Microphone · User’s manual ·...

  • Page 9: Name Of Each Part And Function Description

    All manuals and user guides at all-guides.com 4.2 Name of Each Part And Function Description 4.2.1 CAVS IPS-11G Karaoke Station 4.2.1.1 Front / Top Side Power LED: Indicates the system power status (on/off) · IR sensor: Receives remote control signal. For proper operation, be sure that there is no obstacle ·...
  • Page 10 All manuals and user guides at all-guides.com 4.2.1.3 Back Side SPDIF connector for digital audio output, S-Video connector for high-resolution video output, A/V connector for RCA 2 Channel audio and composite video output, 9V DC power input terminal, and POWER ON/OFF Switch are located on the back side.
  • Page 11 All manuals and user guides at all-guides.com 4.2.2 Remote Controller...

  • Page 12: Installation And Connection

    Connect your USB memory device, such as iPod®, MP3 player, MP4 player, USB memory stick, USB card reader, or USB hard drive, to CAVS IPS-11G Karaoke Station. Use the USB cable that came with your USB memory device to connect.

  • Page 13: Power Connection

    5.5.1 Connecting to composite output (most commonly used) Using the yellow connector of AV cable, connect the CAVS IPS-11G AV out terminal with VIDEO IN or COMPOSITE IN terminal of TV. Please refer to the user’s manual of your TV to find the VIDEO IN terminal.
  • Page 14 All manuals and user guides at all-guides.com 5.5.2 Connecting to S-VIDEO output If your TV has S-Video input terminal, you can enjoy high quality video using S-Video cable (not included) from the S-Video out terminal of CAVS IPS-11G to the S-Video input terminal of your TV.

  • Page 15: Audio Connection

    5.6.1 Connecting to analog audio output (most commonly used) Using the white and red connector of AV cable, connect the CAVS IPS-11G AV out terminal to the AUDIO IN terminal of TV or amplifier. Please refer to the user’s manual of your TV or amplifier to find the AUDIO IN...
  • Page 16 If your AV receiver has a digital audio input terminal (coaxial), you can enjoy 5.1ch audio when playing back 5.1ch audio files. Using the digital audio cable (not included), connect SPDIF digital audio out terminal of CAVS IPS-11G with digital audio input terminal (coaxial terminal) of your AV receiver. Please refer to the user’s...

  • Page 17: Microphone Connection

    All manuals and user guides at all-guides.com 5.7 Microphone Connection CAVS IPS-11G has a built-in dual microphone mixer with 3.5mm mini jack connectors for 2 microphones. Connect the microphones (one included) into the mini jack connectors. Turn on the power switch located on the microphone handle.

  • Page 18: Operation

    The POWER key in the remote control only works when the POWER switch in the back side of CAVS IPS-11G is turned on. This state is called standby mode. When not in use, turn off the POWER switch in the back side of the unit.
  • Page 19 You can choose any icon by using the ◄/► keys and pressing the ENT key. You can return to Main menu from any part of operation by pressing HOME key anytime. You can disconnect your USB memory device anytime from CAVS IPS-11G. Remote control keys: POWER: Turn on/off CAVS IPS-11G. · HOME: Go to the Main menu ·...

  • Page 20: Photos Mode

    6.1 Photos mode Photos mode reads and plays image files saved under a folder named Photos in your digital devices. The folder Photos may contain multilevel sub-folder structure. CAVS IPS-11G can play back image files of format JPG(JPEG), BMP, and GIF.
  • Page 21 All manuals and user guides at all-guides.com Remote control keys in Photos mode: ESC: Stop the playback or go back to the previous menu. · ENT ( ): Select a highlighted menu or play a highlighted file. Press to pause in playback. ·...

  • Page 22: Music Mode

    All manuals and user guides at all-guides.com 6.2 Music mode In Music mode, CAVS IPS-11G reads and plays MP3 music files saved under a folder named MUSIC in your USB memory device. The folder MUSIC may contain multilevel sub-folder structure. Select a song file and press ENT to begin playback.

  • Page 23: Videos Mode

    For iPod®, the video files stored through iTunes® is encrypted in a proprietary format and cannot be viewed by CAVS IPS-11G. To play by CAVS IPS-11G, the video files must be stored into iPod® as USB memory device, shown in Section 6.5.

  • Page 24: Files Mode

    All manuals and user guides at all-guides.com If a video file does not include an audio file or an audio file of a supported format by CAVS IPS-11G, you will not hear the audio portion of the video file. Please check the file format for proper operation.

  • Page 25: Storing Files

    Next, copy all files of your choice from PC to the new folder. CAVS IPS-11G utilizes your USB memory device, such as a USB flash drive or MP3 player, as data storage. It has its own multimedia processor and it accesses your device to play the files of photos, music, videos, and karaoke.

  • Page 26: Karaoke

    · Reservation · These functions along with its portability make CAVS IPS-11G unique and ideal for road shows as well as home entertainment. The karaoke songs that CAVS IPS-11G can play are of following file types: MP3 + CDG ·...

  • Page 27: Transferring Karaoke Songs

    All manuals and user guides at all-guides.com Download the song file and save it into your PC. · In your PC, double click on the downloaded file to unzip into MP3, MCG, and CDG files. You need only · two of the files, MP3 + CDG or MP3 + MCG. Go to any Karaoke Download website of your choice.

  • Page 28: Playing Karaoke Songs

    MCG Manager program. Song file, MP3 + MCG, may have been transferred simply by using Copy & Paste commands of Windows into a USB memory device. To play the karaoke songs in your USB memory device, Connect your USB memory device to CAVS IPS-11G. · From the Main menu, go to Files mode.
  • Page 29 In this section, we consider the case in which the song files are transferred using the MCG Manager program into a USB memory device. The MCG Manager program organizes the song files such that CAVS IPS-11G Display more than 10,000 songs per folder.
  • Page 30 All manuals and user guides at all-guides.com In BY SINGER menu, use the ◄/► keys to select the first character of your search. Next use the keys to change the cursor position, and use the ◄/► keys to select the second character of your search. Singers with matching names will be displayed.

  • Page 31: Using Microphones

    CAVS IPS-11G Karaoke Station has a built-in dual microphone mixer with volume and echo level controls. To use a microphone in conjunction with CAVS IPS-11G: Connect AV (analog audio) out terminal of CAVS IPS-11G to AUDIO IN terminal of your TV or amplifier. ·...

  • Page 32: Firmware Update

    8.1 Downloading firmware Download the latest firmware for CAVS IPS-11G from www.cavsusa.com and save it in your PC. Double click on the downloaded file to unzip it into “klinki2.rom” file. Connect your USB memory device to PC and copy the “klinki2.rom”...
  • Page 33 Press SETUP key to go to the Setup menu. Go to PREFERENCES, VERSION MODE and ON to check the firmware version. Press SETUP key to return to Setup menu. Press again to exit Setup menu. 8.7 Starting CAVS IPS-11G after firmware update After the firmware update, re-connect your digital device and power on the CAVS IPS-11G.

  • Page 34: Setup System Configuration

    All manuals and user guides at all-guides.com 9. Setup system configuration Press SETUP key to go to the Setup menu. Highlight the menu item you wish using /▼, ◄/► keys and press ENT to select. 9.1 PHOTO SETUP 9.1.1 TRANSITION MODE Select a transition speed in photo playback.

  • Page 35: Music Setup

    All manuals and user guides at all-guides.com 9.1.2 DIGEST STYLE. Select the thumbnail matrix style. 9.2 MUSIC SETUP 9.2.1 REPEAT MODE Select the repeat mode in music playback. You can also use the REPEAT key in the remote control.

  • Page 36: Movie Setup

    All manuals and user guides at all-guides.com 9.3 MOVIE SETUP 9.3.1 REPEAT MODE Select the repeat mode in movie playback. You can also use the REPEAT key in the remote control.

  • Page 37: Slide Show Setup

    All manuals and user guides at all-guides.com 9.4 SLIDE SHOW SETUP 9.4.1 SLIDE SHOW MODE Select from manual/auto transition. For manual transition, use ◄/► or keys to move backward/forward. For auto transition, select the time in INTERVAL TIME below.
  • Page 38 All manuals and user guides at all-guides.com 9.4.2 FOLDER REPEAT Select the repeat mode in photo playback. You can also use REPEAT key in the remote control. 9.4.3 INTERVAL TIME Select the interval time per picture in photo playback. Interval Time becomes effective only when SLIDE SHOW MODE is set at AUTO.

  • Page 39: Preferences

    All manuals and user guides at all-guides.com 9.4.4 TRANSITION Select the style of photo transition in photo playback. You can also use the AV SEL key. 9.5 PREFERENCES 9.5.1 TV TYPE Select the TV type. MULTI SYSTEM · NTSC · ·...
  • Page 40 All manuals and user guides at all-guides.com 9.5.2 TV DISPLAY Select the aspect ratio of TV display. NORMAL/PS: Normal (4:3) / pan & scan display. · NORMAL/LB: Normal (4:3) / letter box display. · WIDE: 16:9 Wide screen display. · 9.5.3 SPDIF OUTPUT Select the type of digital audio output.
  • Page 41 All manuals and user guides at all-guides.com 9.5.4 OSD LANGUAGE Select the language type for On Screen Display. 9.5.5 SETUP VALUES Reset all settings to the default settings.
  • Page 42 YES: Enable firmware upgrade function. · If a firmware is found inside your USB memory device, CAVS IPS-11G will automatically begin upgrading immediately after you exit the SETUP menu. After the upgrading is completed, UPGRADE MODE will automatically return to NO (disabled).

  • Page 43: Karaoke Setup

    All manuals and user guides at all-guides.com 9.5.7 VERSION MODE Select ON to display the firmware version information. Press ESC to close. 9.6 KARAOKE SETUP Select OFF / KARAOKE for the karaoke features.

  • Page 44: Speaker Setup

    All manuals and user guides at all-guides.com 9.7 SPEAKER SETUP Select LT/RT or STEREO for the analog audio output. 9.8 EXIT SETUP Select EXIT SETUP to exit Setup menu. Also press SETUP key to exit or press ESC key to return to previous menu.

  • Page 45: Faq (Trouble Shooting)

    All manuals and user guides at all-guides.com 10. FAQ (Trouble shooting)

  • Page 46: Limited Warranty

    WHAT WE WILL DO: If this product is found to be defective, CAVS will repair or replace defective parts at no charge to the original owner. Such repair and replacement services shall be rendered by CAVS during normal business hours at CAVS authorized service centers.
  • Page 47 All manuals and user guides at all-guides.com...
