CAVS 205G Plus Manual

Hide thumbs Also See for 205G Plus:

Advertisement

Table of Contents

12/12/24, 12:30 PM
0. Introduction
CAVS 205G Plus Karaoke Player
New! Built-in Network Server
effortlessly.
For iPhone or iPad: Connect using the Safari browser.
For Android phones and tablets: Connect using the Chrome browser.
The connection is universal and can be made with a simple scan of QR code.
Simple to Play
- When connected, you can search, reserve, and play the songs using your phone or tablet. Given the thousands or tens of thousands of digitally
stored songs, this is almost necessary unless you don't mind printing stacks of paper song books.
Another advantage to using a phone or tablet is that the song search can be done by Voice Command. Simply speak the title or artist's name, and the matching
songs will instantly appear. This Voice Command feature supports multiple languages including English, Spanish, French, Chinese, Japanese, etc.
Additionally, you have the option to play the songs using the front panel buttons or the remote control.
Simple to Setup
- To setup, you can connect the 205G Plus player to a TV using a single HDMI cable for all of the video, audio, and microphone outputs. The
player's internal digital mixer combines all three outputs into one. Additionally, the player features RCA connectors for traditional Audio Video outputs.
Simple to Manage
- Load up to 64,000 songs on a single USB flash drive or SD card, or up to 500,000 songs on a 2 TB hard drive. Use the
freeware to add songs effortlessly, and play each song instantly without delays.
1. Features
Play CD+G, Super CD+G, CD, VCD, and DVD discs
Play MP3+G, Super CD+G, AVI, and MP4 digital files
Play from compact discs, USB flash drive, and SD Cards
Connect using phones and tablets to
Search songs by typing or Voice Command
Play, stop, pause, reserve, and cancel songs
Control volume, pitch, and echo
HDMI connection for all combined video, audio, and microphone outputs
RCA connections for traditional AV Stereo outputs
Extract Super CD+G and CD+G discs
Record Super CD+G and CD+G karaoke singing with lyricd video
Volume control, Pitch control, Echo control
Score, Bill Acceptor, Coaxial digital output
localhost:50006/userManual_205GPlus_2.htm
CAVS 205G Plus Karaoke Player
- CAVS 205G Plus Karaoke player now features a built-in network server, allowing you to connect to any phone or tablet
Untitled Document
MCG Manager
1/38

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 205G Plus and is the answer not in the manual?

Questions and answers

Related Manuals for CAVS 205G Plus

Summary of Contents for CAVS 205G Plus

  • Page 1 Simple to Setup - To setup, you can connect the 205G Plus player to a TV using a single HDMI cable for all of the video, audio, and microphone outputs. The player's internal digital mixer combines all three outputs into one. Additionally, the player features RCA connectors for traditional Audio Video outputs.
  • Page 2 12/12/24, 12:30 PM Untitled Document 2. Accessories 1. Network router 2. QR codese 3. Remote contoller 4. Super CD+G disc with 200 Golden songs 5. Microphone 6. Rackmount ears 7. RCA AV cable 8. HDMI cable 3. Description localhost:50006/userManual_205GPlus_2.htm 2/38...
  • Page 3 Untitled Document This section describes the assigned functions for each button and indicator on the CAVS 205G Plus, Remote controller, Network router, and QR codes. It is meant to serve you as reference section for your reading of "4. How to operate".
  • Page 4 12/12/24, 12:30 PM Untitled Document 3. Network router localhost:50006/userManual_205GPlus_2.htm 4/38...
  • Page 5 12/12/24, 12:30 PM Untitled Document localhost:50006/userManual_205GPlus_2.htm 5/38...
  • Page 6 First QR code is for the network router. Scan it using your phone or tablet and it will set the Wi-Fi setting of the phone or tablet to the network router. Second QR code is for the CAVS 205G Plus player. Scan it using your phone or tablet and it will connect the phone or tablet to CAVS 205G Plus player.
  • Page 7 4. How to operate using phones and tablets 4.1 Setup To setup the CAVS 205G Plus karaoke player, Connect 9.DV 5V INPUT on the back panel to a wall outlet using an enclosed AC adapter. Connect 7.HDMI OUT or 1.COMPOSITE VIDEO OUT on the back panel to a TV.

  • Page 8: Loading Songs

    4.2 Loading songs The CAVS 205G Plus karaoke player offers versatile playback options, supporting songs from compact discs, USB flash drives, and SD cards. To load songs onto these media, the MCG Manager, developed under US and international patents, provides efficient processing. Here's what you can...
  • Page 9 Amazon tablets, Amazon Fire It's noteworthy that connecting to the CAVS 205G Plus requires no special app to be downloaded or installed onto the user's device. This eliminates the need for users to search for and install specific apps, which can be challenging given the vast variety and versions of phones and tablets available.
  • Page 10 Confirm to switch the Wi-Fi setting. Note that CAVS Network will not have Internet connection as it operates within its local network. Next scan the QR code for the URL address of the CAVS 205 Plus player. A popup message will appear with "192.168.0.100:3500" reading. Tap on the popup message.
  • Page 11 12/12/24, 12:30 PM Untitled Document Open a camera app, and scan the QR code for the network router. A popup message will appear with "CAVS Network" reading. Tap on the popup message. The Wi-Fi setting will change to "CAVS Network". Note that CAVS Network will not have Internet connection as it operates within its local network.
  • Page 12 Untitled Document 4.3.3 Lenovo Tab P12 with Android 14 Open a camera app, and scan the QR code for the network router. A popup message will appear with "CAVS Network" reading. Tap on the popup message. The Wi-Fi setting will change to "CAVS Network". Note that CAVS Network will not have Internet connection as it operates within its local network.
  • Page 13 12/12/24, 12:30 PM Untitled Document Next scan the QR code for the URL address of the CAVS 205 Plus player. A popup message will appear with "192.168.0.100:3500" reading. Tap on the popup message. A web browser will open showing the Songbook of the CAVS 205G Plus player with the URL address "192.168.0.100".
  • Page 14 Refer to the following examples to activate the Voice Command feature in your phone or tablet. 4.4.1.2.1 Apple (iPhone 6S) Apple device (iPhone 6S) is connected to the 205G Plus player, showing the Songbook in the Safari browser. Press the Search icon marked in red.
  • Page 15 12/12/24, 12:30 PM Untitled Document The Search menu will appear. 1. Select the search category by pressing the menu. 2. Tap on the search field to bring up the keyboard. In the keyboard, press the microphone button to activate the Voice Command. The keyboard changes to the Voice Command screen, indicating that it is ready to accept your vocal input.
  • Page 16 12/12/24, 12:30 PM Untitled Document Speak clearly the search word(s) into the Apple device. Here we speak "Yesterday" into the iPhone. The word(s) will appear in the search field. Press the search button to start searching. localhost:50006/userManual_205GPlus_2.htm 16/38...
  • Page 17 12/12/24, 12:30 PM Untitled Document The matching songs of the search will appear on the screen. Select a song and proceed to reserve the song. To search in foreign languages, press the globe button in the keyboard. It will toggle between the added languages, and change the keyboard layout accordingly. To add or remove a language, please refer to the user manual of the Apple device.
  • Page 18 Next you can type in the search word(s) or press the microphone button to activate the Voice Command following the steps shown above. 4.4.1.2.2 Android (Samsung Galaxy S7) Android device (Samsung Galaxy S7) is connected to the 205G Plus player, showing the Songbook in the Google Chrome browser. Press the Search icon marked in red.
  • Page 19 12/12/24, 12:30 PM Untitled Document The Search menu will appear. 1. Select the search category by pressing the menu. 2. Tap on the search field to bring up the keyboard. In the keyboard, press the microphone button to activate the Voice Command. The microphone button changes to blue color, indicating that it is ready to accept your vocal input.
  • Page 20 12/12/24, 12:30 PM Untitled Document Speak clearly the search word(s) into the Android device. Here we speak "Yesterday" into the Samsung Galaxy S7. The word(s) will appear in the search field. Press the search button to start searching. The matching songs of the search will appear on the screen. localhost:50006/userManual_205GPlus_2.htm 20/38...
  • Page 21 12/12/24, 12:30 PM Untitled Document Select a song and proceed to reserve the song. To search in foreign languages, slide the Shift button in the keyboard. It will change to an added languages, and change the keyboard layout accordingly. To add or remove a language, please refer to the user manual of the Android device. Here we show the language changed to Korean.
  • Page 22 5. Artist: Tap on an artist and you will see all the songs of the artist in the song list. Tap on any song to reserve. 4.4.2 How to play and shuffle the reserved songs Tap on the Queue button on the right side of the CAVS Songbook. Following screen will appear. localhost:50006/userManual_205GPlus_2.htm 22/38...
  • Page 23 To access the advanced features, navigate to the URL address "192.168.0.100\admin" in your phone or tablet. Following screen will appear. A slight difference from the CAVS Songbook screen is that the Setting button is no longer grayed out. Tap on the Setting button.
  • Page 24 5. Restart and Restart & Rebuild: Press the Restart button to restart the CAVS Songbook program. Press the Restart & Rebuild button to restart the program and also rebuild the song list. In both cases, the following screen will appear indicating the restart or restart & rebuild of the Songbook program.
  • Page 25 To change the songs, i.e. change the source media, such as compact disc, USB flash drive, USB hard drive, or SD card that contains the songs, take the currently inserted media out first. Then insert the new media into the 205G Plus player.

  • Page 26: Configuring Router

    205G Plus player and the assigned QR codes would also stop working. This section describes how to re-configure the network router from the factory default mode so that it would work with the 205G Plus player again and the QR codes will also work as before.
  • Page 27 12/12/24, 12:30 PM Untitled Document 1. Connect: Power on the router and connect by Wi-Fi or LAN from your PC. When using Wi-Fi, the router name (SSID) and password (WPA) in the default mode are written on the bottom of the router. 2.
  • Page 28 Untitled Document Next select "Use Default MAC Address" and click Nect. Next type in "CAVS Network" for the SSID and "205G Plus" for the WPA in both 2.4G and 5G Wireless settings. Click Next to confirm the settings so far.
  • Page 29 In the next screen, the router will show an Internet connection error. Do not try to connect again. Instead click on the Internet Setting in the Windows taskbar. From the available networks, select "CAVS Network" and click Connect. Next type "192.168.0.1" in the URL field for the administration access.
  • Page 30 In the "Advanced" page, select "Network". Select "DHCP". In the "DHCP" page, click on "ADD". Next put in the MAC address of the 205G Plus player which you need to contact service@cavsusa.com for the information. Put in the IP address as "192.168.0.100". Click Save. localhost:50006/userManual_205GPlus_2.htm...

  • Page 31: Basic Operation

    5. How to operate using the Front Panel and the Remote Control The CAVS 205G Plus karaoke player is an upgrade from the regualr CAVS 205G USB karaoke player with the addition of a built-in network server. This upgrade enables the phones and tablets to operate the players in selecting and playing songs.
  • Page 32 12/12/24, 12:30 PM Untitled Document localhost:50006/userManual_205GPlus_2.htm 32/38...

  • Page 33: Karaoke Operation

    12/12/24, 12:30 PM Untitled Document 5.2 Karaoke Operation localhost:50006/userManual_205GPlus_2.htm 33/38...
  • Page 34 12/12/24, 12:30 PM Untitled Document localhost:50006/userManual_205GPlus_2.htm 34/38...
  • Page 35 12/12/24, 12:30 PM Untitled Document 6. Setup localhost:50006/userManual_205GPlus_2.htm 35/38...
  • Page 36 12/12/24, 12:30 PM Untitled Document localhost:50006/userManual_205GPlus_2.htm 36/38...
  • Page 37 12/12/24, 12:30 PM Untitled Document 7. Troubleshooting 8. Specification localhost:50006/userManual_205GPlus_2.htm 37/38...
  • Page 38 12/12/24, 12:30 PM Untitled Document localhost:50006/userManual_205GPlus_2.htm 38/38...
