Furthermore take care about the connecting wires from the power supply to
the CBH Advanced System, don't damage this by overrun.
Assure free space for movement of application in both directions to avoid
blockade.
The appliance is only to be used with the power supply unit provided with the
appliance.

Safety issues

The builder of the equipment shall ensure that the use of the component
complies with relevant standards – like the Machine Directive. Care must be
taken to avoid squeezing of cables as it can cause movement of the system!
The SMPS001/002/006 must not be packed in heat insulating material, but
must be placed so that it can emit waste heat to the surroundings. There are
no ventilation holes to consider, the SMPS emits heat through its surface.
Only the power supply type SMPS001, SMPS002 or SMPS006, shall be used
with the system (CBH Advanced System).
Please observe that the actuators LA27 used for CBH Advanced systems are
with Hall sensor and are not compatible with CBH Basic systems
Please observe that if you use the SMPS001 or SMPS002 the CBH Advanced
must be configured first as the CBH Advanced is standard set to 29V DC. This
is done via the CBH configurator. BA001 will not be charged
It is possible only to use 1 power supply (SMPS001, SMPS002 or SMPS006) for
2 CBH systems. Remember speed may decrease when running 2 systems at the
same time.
