Summary of Contents for Linak HOMELINE LA10 system

  • Page 1 LA10 system User Manual...
  • Page 2: Table Of Contents

    Mounting the Charging Point CP002/CP003 ���������������������������������������������������������������������������� 17 Mounting the BP10 bracket ����������������������������������������������������������������������������������������������������� 18 Pairing the remote ������������������������������������������������������������������������������������������������������������������� 19 Initialising the system ��������������������������������������������������������������������������������������������������������������� 19 Re-initialising the system ���������������������������������������������������������������������������������������������������������� 19 Replacing the battery ��������������������������������������������������������������������������������������������������������������� 20 Disposal of LINAK products ���������������������������������������������������������������������������������������������������������� 21 LINAK application policy ��������������������������������������������������������������������������������������������������������������� 22...
  • Page 3: Preface

    This User Manual does not address the end-user� It is intended as a source of information for the equipment or system manufacturer only, and it will tell you how to install, use and maintain your LINAK electronics� The manufacturer of the end product has the responsibility to provide a User Manual where relevant safety information from this manual is passed on to the end user�...
  • Page 4 LA10 system | This User Manual is valid for the following products: (See the first 3 - 5 characters on the label) Actuators: LA10 Controls: BP11, BP12, and BP13 Charging Point: CP001, CP002, and CP003 Accessory: BLE2DC, BA002 Power supply: SMPS001 or SMPS006...
  • Page 5: Important Information

    LA10 system | Important information Important information on LINAK products can be found under the following headings: ® Warnings Failing to follow these instructions may cause accidents resulting in serious personal injury� Recommendations Failing to follow these instructions can result in product damage�...
  • Page 6: Before Installation, Re-Installation, Or Troubleshooting

    • System connection� The individual parts must be connected before the SMPS is connected to the mains� See the User Manual for LINAK actuators, if necessary� During operation • If the SMPS makes unusual noise or smells, switch off the mains voltage immediately�...
  • Page 7: Declarations

    DECLARATION OF INCORPORATION OF PARTLY COMPLETED MACHINERY 2006/42/EC ANNEX II B LINAK A/S Smedevænget 8 DK - 6430 Nordborg Herewith declares that LINAK HOMELINE® products as characterized by the following models and types: Control Boxes CB9H, CBH Advanced, CBH Basic Linear Actuators...
  • Page 8: Eu Declaration Of Conformity

    Smedevænget 8 DK - 6430 Nordborg hereby declares under our sole responsibility that LINAK Actuator System (LA10) for use in adjustable recliner chairs for the purpose of raising and lowering the back and foot sections: With main component (marked with CE)
  • Page 9: Uk Declaration Of Conformity

    Smedevænget 8 DK - 6430 Nordborg hereby declares under our sole responsibility that LINAK Actuator System (LA10) for use in adjustable recliner chairs for the purpose of raising and lowering the back and foot sections: With main component (marked with CE)
  • Page 10: Description Of The Homeline ® La10 System

    LA10 system | 10 Description of the HOMELINE LA10 system ® The LA10 system consists of one or more Linear Actuators LA10, a Bluetooth dongle, a control unit, and ® a charging point� The solution is designed for adjustable recliner chairs and meets user requirements for reduced number of cables in the system�...
  • Page 11: Installation

    LA10 system | 11 Installation The connection cables between units on the bus (from battery to LA10 and between the LA10 actuators) should be kept as short as possible – use the recommended 400 mm or 800 mm cables and avoid excess cable�...
  • Page 12: Connecting The La10 System With Ble2Dc

    LA10 system | 12 Connecting the LA10 system with BLE2DC 1� Gather all parts for the LA10/BLE2DC system� Figure 2 All parts of the LA10/BLE2DC system 2� Plug the Bluetooth plug into one of the actuators� 3� Connect the actuators using the connection cable�...
  • Page 13 LA10 system | 13 4� Connect the Charging Point CP001/002/003 to one of the actuators and connect the power cable� 5� Connect the power cable to the power supply�...
  • Page 14: Connecting The La10 System With Ba002

    LA10 system | 14 Connecting the LA10 system with BA002 1� Gather all parts for the LA10/BA002 system� Figure 3 All parts of the LA10/BA002 system 2� Plug one of the connection cables into one of the actuators and connect it to the BA002� 3�...
  • Page 15 LA10 system | 15 4� Connect the Charging Point CP001/002/003 to one of the actuators and connect the power cable� 5� Connect the power cable to the power supply�...
  • Page 16: Mounting The Ba002

    LA10 system | 16 Mounting the BA002 Do not pack the BA002 in heat insulating material� Ensure minimum 20 mm distance to objects close to the BA002 to allow it to emit heat through its surface to the surroundings� Without mounting bracket 1�...
  • Page 17: Charging The Ba002

    Charging the BA002 The BA002 can be charged via the Switch Mode Power Supply SMPS001 or SMPS006 using a DC cable with 2-poled Mini-Fit plug� LINAK offers various cables with straight plug which can be used (e�g� 0705894-200)� Notes: •...
  • Page 18: Mounting The Bp10 Bracket

    LA10 system | 18 Mounting the BP10 bracket The remote control BP10 contains a magnet that could affect the function of a medical device (such as a pacemaker)� Please read the instructions of the medical device and keep a safe distance for safe use, if required�...
  • Page 19: Pairing The Remote

    LA10 system | 19 Pairing the remote When connecting the system to power, it will automatically be in pairing mode for three minutes� The pairing mode stops when a paired remote sends a command� 1� Press the two upper buttons of the control unit to pair it with the system� For BP11: press the ‘up’...
  • Page 20: Replacing The Battery

    LA10 system | 20 Replacing the battery This product contains a coin battery� A coin battery can cause serious internal chemical burns if swallowed� The CR2032 battery can be replaced when needed� 1� Press the battery cover down and slide to loosen it� 2�...
  • Page 21: Disposal Of Linak Products

    Some of these main groups can be further divided into subgroups; e�g� metal can be divided into steel/ aluminium/copper and plastic can be divided into ABS/PA/PE/PP� As an example, the table below breaks down the different components in LINAK products to various recycling groups:...
  • Page 22: Linak Application Policy

    LINAK shall be responsible solely that the LINAK products comply with the specifications set out by LINAK and it shall be the responsibility of the LINAK customer to ensure that the specific LINAK product can be used for the application in question�...
  • Page 23 For the same reason, LINAK cannot guarantee the correctness and actual status of imprinted information on its products. LINAK uses its best efforts to fulfil orders. However, for the reasons mentioned above, LINAK cannot guarantee availability of any particular product at any given time. LINAK reserves the right to discontinue the sale of any product displayed on its website or listed in its catalogues or in other written material created and produced by LINAK, LINAK subsidiaries, or LINAK affiliates.
