CBH Advanced systems
User manual
LINAK.COM/HOMELINE
Page 1 of 32

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CBH Advanced and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Linak CBH Advanced

Summary of Contents for Linak CBH Advanced

  • Page 1 CBH Advanced systems User manual LINAK.COM/HOMELINE Page 1 of 32...

  • Page 2: Table Of Contents

    ....................10 ® Warranty............................10 Maintenance..........................10 ETL-marking .............................11 Description of the HOMELINE CBH Advanced system ..............12 ® Mounting guideline for the CBH ....................12 Cable relief ..........................13 How to mount the locking device ....................16 Disposal of LINAK’s products .......................17 Main groups of disposal ........................17 Disposal of batteries ........................17...

  • Page 3: Preface

    This User Manual does not address the end-user. It is intended as a source of information for the manufacturer of the equipment or system only, and it will tell you how to install, use and maintain your LINAK electronics. It is the responsibility of the manufacturer of the end-use product to provide a User Manual where relevant safety information from this manual is passed on to the end-user.

  • Page 4: Valid For

    Valid for: This User Manual is valid for the following products: (See the first 3 - 5 characters on the label) Actuators: LA27, LA31 and LA40 Control box: CBH1220A and CBH1300A Power supply: SMPS001, SMPS002 or SMPS006 Controls: HB20, HC05 Wireless, HC10 Wireless, HC20 Wireless, HC30 Wireless Accessories: BA001, Lightplug001, LED Lightbox001, DC Connector001, USB Connector001, MD1000D2, LEDLightRail001, Bluetooth...

  • Page 5: Important Information

    Only the power supply type SMPS001, SMPS002 or SMPS006, shall be used with the system (CBH Advanced System). The power supply shall not be covered while operating to allow sufficient cooling of this appliance.

  • Page 6: Safety Issues

    Hall sensor and are not compatible with CBH Basic systems Please observe that if you use the SMPS001 or SMPS002 the CBH Advanced must be configured first as the CBH Advanced is standard set to 29V DC. This is done via the CBH configurator. BA001 will not be charged It is possible only to use 1 power supply (SMPS001, SMPS002 or SMPS006) for 2 CBH systems.

  • Page 7: Before Installation, Re-Installation Or Troubleshooting

    • Make sure that the voltage of the control box/SMPS is correct before the system is connected to the mains. • System connection. The individual parts must be connected before the control box /SMPS is connected to the mains. See the User Manual for LINAK actuators, if necessary. During operation •...

  • Page 8: Only For Eu Markets

    Only for EU markets This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

  • Page 9: Repairs

    ® DECLARATION OF INCORPORATION OF PARTLY COMPLETED MACHINERY LINAK A/S Smedevænget 8 DK - 6430 Nordborg Herewith declares that LINAK HOMELINE® products as characterized by the following models and types: Control Boxes CB7, CB9H, CBH Advanced, CBH Basic Linear Actuators...

  • Page 10: Misc. On The Homeline ® System

    There is a 36 months’ warranty on the HOMELINE products CBH Advanced Systems against manufacturing faults from the production date of the individual products (see label). LINAK A/S’ warranty is only valid in so far as the equipment has been used and maintained correctly and has not been tampered with.

  • Page 11: Etl-Marking

    ETL-marking Due to space limitations, the complete ETL-marking demands are not represented on the marking plates. The full ETL Recognized Component markings are shown here. C/N 120690 Conforms to UL962 Cert. to CSA Std. C22.2 No. 68-09 ETL Recognized Component mark for Canada and United States C/N 9901916 Conforms to UL962...

  • Page 12: Description Of The Homeline ® Cbh Advanced System

    When the piston rod is at the innermost position, it must be possible to pull it out manually to its full travel length and to press it in again without much resistance and without using the motor. If this is not possible, contact your nearest LINAK dealer.

  • Page 13: Cable Relief

    Cable relief: The CBH features a cable relief option. By using these small holes on the CBH, you can tie the DC cables from the SMPS unit to the control box by use of standard cable ties. It is recommended to use the cable relief especially if the control box is exposed to movement.
  • Page 14 CBH) Back/leg+neck/foot/hi-lo adjustment system A typical single actuator system for three adjustments consists of 1 x CBH Advanced (3 channels), 3 x LA27 / 31 / 40, 1 x SMPS and a hand control (A Bluetooth hand control requires a Bluetooth Adapter plugged into the CBH) ®...
  • Page 15 How to pair the Bluetooth Adapter and the Bed Control App ® Plug the Bluetooth Adapter into a powered CBH. The pairing mode will last 3 minutes and is indicated with a blue flashing LED light that is visible through the transparent plastic.
  • Page 16 Now the light will give a long blink and indicate that the hand control and the Bluetooth Adapter are paired up. ® Hand controls with SW0077075 ver. 1.04 or newer supports dual pairing: Pairing one hand control to two CBH Advanced using Bluetooth Adapters. ®...
  • Page 17 How to connect the LED Light Rail to the CBH Simply connect the LED Light Rail to the CBH Advanced by using the RJ45 plug. CBH Advanced SMPS LED Light Rail Page 17 of 32...

  • Page 18: How To Mount The Locking Device

    How to mount the locking device (0705889) To ensure optimal cable relief on the SMPS001/002 a locking device (0705889) should be used. Follow the guide below on how to fix the locking device on the SMPS. 1. Take the SMPS 2.

  • Page 19: Disposal Of Linak's Products

    Disposal of LINAK’s products As LINAK’s customers often ask us how our products can be disposed of or scrapped we have prepared this guidance that enables a classification to different waste fractions for recycling or combustion. Guidance We recommend that our products be disassembled as much as possible and divided into different waste groups for recycling or combustion.

  • Page 20: Labels

    Labels Label for HC20RF Label for HB22RF Label for LA27 Label for USB Connector Label for DC Connector Label for LED Light Rail Label for CBH Basic Label for LED Lightbox Label for Massage Motor Label for SMPS001 Label for SMPS002 Label for SMPS006 Page 20 of 32...
  • Page 21 DRAWING APPENDIX CBH Advanced Page 21 of 32...
  • Page 22 SMPS001 SMPS002 Page 22 of 32...
  • Page 23 SMPS006 Page 23 of 32...
  • Page 24 LA27 Drawing no.:LA27001B LA31 HOMELINE Page 24 of 32...
  • Page 25 LA40 HOMELINE HB20RF Hand Control Page 25 of 32...
  • Page 26 HC05 Wireless HC10 Wireless Page 26 of 32...
  • Page 27 HC20RF Hand Control Massage motor MD1 Page 27 of 32...

  • Page 28: Addresses

    HC30 Wireless HC32BL1000 HC33BL1000 HC34BL1000 Page 28 of 32...
  • Page 29 BA001 182.8 13.6 Bluetooth Adapter ® 255485 mm³ Iteration: 0 BA001-DRAW Page 29 of 32...
  • Page 30 LED Light Rail Lightplug Page 30 of 32...
  • Page 31 Iter.: accessory_lys.asm ACCESSORY_LYS Confidential: Property of LINAK A/S GROUP HEADQUARTER, DK-6430 NORDBORG, DENMARK Phone +45 73 15 15 15 ; FAX +45 74 45 80 48. Not to be handed over to, copied or used by third party. Material: Date:...
  • Page 32 ACCESSORY_USB Confidential: Property of LINAK A/S GROUP HEADQUARTER, DK-6430 NORDBORG, DENMARK Phone +45 73 15 15 15 ; FAX +45 74 45 80 48. Not to be handed over to, copied or used by third party. LINAK APPLICATION POLICY The purpose of the application policy is to define areas of responsibilities in relation to applying a LINAK product defined as hardware, software, technical advice, etc.
  • Page 33 While LINAK uses its best efforts to fulfil orders, LINAK cannot, for the same reasons as mentioned above, guarantee the availability of any particular product. Therefore, LINAK reserves the right to discontinue the sale of any product displayed on its website or listed in its catalogues or other written material drawn up by LINAK.
