- Page 1 OPERATING MANUAL ba77048e01 02/2014 ® photoLab PHOTOMETER...
- Page 2 ® photoLab • Photometer Scope of delivery • Power pack • Product documentation Copyright © 2016 Xylem Analytics Germany GmbH Printed in Germany. ba77048e01 02/2014...
-
Page 3: Table Of Contents
Contents Overview ....... . 4 Description of the operating elements ... . 4 Identifying the connectors . -
Page 4: Overview
Overview Description of the operating elements a Display b Menu call/Enter key c Scroll key d Absorbance measurement key e Concentration measurement key f Notch for cell alignment g Round cell shaft h Storage space for analysis regulations (short form) i Cover with integrated on/ off switch j Rectangular cell shaft... -
Page 5: Selecting And Calling Up The Menu Items
Overview Selecting and calling up the menu items – To switch on the photometer, open the cover. – Press The following display appears: Example: The documentation menu item is preselected in the setup menu (z). Select a menu item, e. g. meter setup: –... -
Page 6: Safety
Safety This operating manual contains basic instructions to manual before working with the meter. be followed in the commissioning, operation and The operating manual must always be available in the maintenance of the meter. Consequently, all vicinity of the meter. responsible personnel must read this operating Authorized use The photometer is authorized exclusively for... -
Page 7: Technical State Of The Meter
Safety Technical state of the meter It is the responsibility of the operator to continuously Safe operation is no longer possible if observe the overall technical condition (externally the equipment has been damaged in transport recognizable deficits and damage as well as ... -
Page 8: Commissioning
Commissioning The photometer operates at an environmental Before putting the photometer into service, wait until it temperature of +5 °C to +40 °C. During transport from has adapted to the new environmental conditions cold to warm surroundings, condensation can form (see also chapter T , in the F ECHNICAL... -
Page 9: Measuring The Concentration
Measuring the concentration – Call up the concentration measuring mode by actuating Measuring mode, concentration Measuring using cell tests – Insert the round cell with barcode into the round cell shaft until it clicks into place. Align the line mark to the notch of the photometer. The photometer reads the barcode of the round cell and automatically selects the relevant method. -
Page 10: Measuring Using Reagent Tests
Measuring the concentration Measuring using reagent tests – Insert the AutoSelector into the round cell shaft. Align the line mark to the notch of the photometer. The photometer reads the barcode and automatically selects the relevant method. – Insert the rectangular cell (vertically, to the right of the slot). -
Page 11: Zero Adjustment
Zero adjustment Zero adjustment is necessary after changing the lamp after the error message, PhotoCheck (AQA1) occurs on initial commissioning if the photometer was mechanically stressed, e.g. percussion, transport if the ambient temperature changed by more than 5 °C since the last zero adjustment ... - Page 12 Zero adjustment Only perform the zero adjustment against distilled water in an optically perfect cell. – Press – In the setup menu, call up the meter setup submenu. The following display appears: – Call up the zero adjustment submenu with –...
-
Page 13: Meter Setup
Meter Setup – To switch on the photometer, open the cover. – Press – In the setup menu, call up the meter setup submenu. The following display appears: This chapter describes the following functions of the meter setup menu: select language ... -
Page 14: Setting The Date/Time
Meter Setup Setting the date/time – Call up the set date/time menu item. – Input the date via the numeric keypad – Confirm with – Input the time via the numeric keypad – Confirm with ba77048e01 02/2014... -
Page 15: Maintenance, Cleaning, Disposal
Maintenance, cleaning, disposal Maintenance - Changing the lamp – Switch off the photometer and disconnect it from – Screw the lamp cover on again the power line – Set up the photometer again and connect it to the – Carefully turn up the photometer and park it safely power line –... -
Page 16: Disposal
Maintenance, cleaning, disposal Disposal Packing The measuring instrument is sent out in a protective transport packing. We recommend: Keep the packing material in case you have to send the measuring instrument back for service. The original packing prevents the measuring instrument from being damaged during transport. -
Page 17: What To Do If
What to do if… The display remains blank Connect the photometer to the line power via the power pack. when switched on In the case of battery operation: Battery empty, charging required (approx. 5h); line operation is possible without restrictions during charging time. appears Battery nearly empty. - Page 18 What to do if… ba77048e01 02/2014...
- Page 20 For more information on how Xylem can help you, go to xyleminc.com. ® Service address: Xylem Analytics Germany Sales GmbH & Co. KG Dr.-Karl-Slevogt-Str. 1 82362 Weilheim Germany Tel.: +49 881 183-325 Fax: +49 881 183-414 E-Mail wtw.rma@xyleminc.com Internet: www.WTW.com Xylem Analytics Germany GmbH Dr.-Karl-Slevogt-Str. 1 82362 Weilheim Germany...
