hager EG470 Instructions For Use

_________________________________________________________________________
http://waterheatertimer.org/Hagar-timers-and-manuals.html
´ §
4 channels time switch
- weekly cycle
User instruction
A
A
B
OF F B
Au to ON
OF F C
Pr og ON OF F
D C
ON OF F
ON
D
t
re se
7 of f
6 au to
5 on
4 r
3 en te
2
1
+
–
ff
on /o
cl ea r
EG470
Working principle :

Time and day setting :

The EG470 is a time switch for the automatic
control of electrical loads.
It is fully programmable with a maximum of 84
Prog Auto
program steps to be divided between the four
channels. Each program step can be applied
to one or several days, maximising the use of
each memory location.
An input lets you simultaneously force the 4
channels to OFF.
1 2
The front cover is sealable preventing unautho-
rised access after completion of programming.
clear on/off
Warning : at the beginning of use, please
reset the device in order to clear the
memory before programming.
1. Press the key
This is achieved by using a pen to push
below
the reset button.
2. Select with key "1" to "7" , the actual day
(1 = Monday, 2 = Tuesday .)
3. Input time with buttons "+" and "-".
Presentation :

Programming channel A :

2 3
Prog Auto
5
A
ON OFF Prog Auto
1 A
ON OFF B
ON OFF C
4
ON OFF
D B
7
C
1 2 3 4 5 6 7
reset
D
1 2
clear on/off enter on auto off
– +
13 6
8 9 10 11 12
clear on/off

Display :

Œ
time
1. Press the key

below "prog" for channel A.
circuit status of channels A, B, C and D
2. Select with keys "1" to "7" the day(s) assigned to
(ON or OFF)
Ž this program step. An arrow appears above each
Indication of manual override on
day selected.
channels A, B, C and D.
3. Input switching time with buttons "+" and "-".

day of the week 4. Input the type of switching with button "on/off"
(1 = Monday, 2 = Tuesday ....) (for the first action ON is automatically proposed).

5. Enter this program step with button "enter".
Indicator of operating mode :
time setting Program additional time settings by repeating steps
prog programming mode 2 to 5..
for channels A, B, C and D

Programming channels B, C and D :

auto running mode
timed override.
Press key
channels B, C or D.

Buttons :

‘ Same way of programming as channel A.
Manual selector to override channels
A B, C and D.

Running Auto mode

’
"1" to "7" selection of the days
“ The switch to automatic mode is made automati-
"clear" : to delete a program step.
cally if no key is pressed for 2 minutes.
”
"on/off": chooses whether the circuit
You can also select the "auto" mode by pressing
is on or off
the key to place the cursor below "auto".
•
"+" and "-" : changes settings
This mode is the current displaying mode.
: to select the operating mode
Display of the time, the day and the state of the
(time setting, programming, running
four channels.
mode or override)
This mode does not allow any modification, except
"enter": to confirm
the winter / summer time change.
"reset"
Press key "+" or "-" and confirm with "enter".
1
To check your program on channels A,
B, C or D :
1. Press the key repeatedly to place the
cursor below "prog" for channel A, B, C or D.
2. Press the key "enter" repeatedly to display
A
A the different program steps (switching
B
C time, days of the week and state of the
D B
channel ON or OFF).
C
3 4 5 6 7
reset
D
To modify or delete a program
– + enter on auto off
step on channels A, B, C or D :
repeatedly to place the cursor
Prog Auto
ON
1 2 3 4 5
clear on/off
– +
1. Press the key repeatedly to place the
cursor below "prog" for channel A, B, C or D.
ON A
A
B 2. Press the key "enter" repeatedly to select
C
the program step to modify or to delete.
D
B
3. Modify :
- switching time with keys "+" or "-"
C
3 4 5 6 7
reset - days assigned with keys "1" to "7".
D
- state of the channel with key "on/off".
To delete a program step, press "clear".
– + enter on auto off
4. press "enter" to confirm.
repeatedly to place the cursor

To override the output :

Permanent override :
The 3 position selector (on - auto - off) for
channels A, B, C or D allows in automatic
mode the output to be overriden ON or OFF.
Prog Auto
ON
to place the cursor below "prog" for
ON
ON
1 2 3 4 5
clear on/off – +
1. Move the 3 position selector for channels
A, B, C or D to "ON" or "OFF"
2. A cursor on the display (in front of
channels A, B, C or D) indicates the
permanent override.
To switch back to automatic mode, move the
selector to "auto".
Timed override :
Prog Auto
OFF
1 2 3 4 5 6 7
clear on/off
– +
The override duration is adjustable from 1 hour
to 47 hours by steps of 1 hour then from 2 to
99 days by steps of 1 day.
The temporary override time period can be dif-
A
ferent on each channel.
A
B
C
D B
Temporary override on channel A.
C
6 7
1. Press the key repeatedly to place the
reset
D
cursor below for channel A.
enter on auto off 2. Input with keys "+" or. "-" the override
duration.
3. Select the state of the output with key
"on/off".
4. Confirm with "enter".
Temporary override on channels B, C or D.
1. Press the key repeatedly to place the
cursor below for channels B, C or D.
2. Use the same process as for channel A.
3. Press the key repeatedly to place the
cursor below "auto" and switch back to
automatic mode.
The channel cursor flashes to indicate that a
timed override has been programmed. After
the duration, the program will resume its
normal course.
To cancel the timed override on channels A,
B, C or D :
Prog Auto
A
A ON
OFF B
C
D
B
C
6 7
1 2 3 4 5
reset 6 7
D
enter on auto off
clear on/off – +
1. Press the key repeatedly to place the
cursor below for channel A, B, C or D.
2. Press "clear" to cancel the timed override.
3. Press the key repeatedly to place the
cursor below "auto" and switch back to
automatic mode.
External input for off override :
This external input lets you simultaneously force off
all 4 channels.
To activate this input, just connect the 230V phase
supply to terminal 20.
A
A
B
This input has priority, even if all 4 channels were
C
manually forced as on.
D B
C
reset

To reset the time switch :

D
Press "reset" to clear the program.
enter on auto off

Technical specifications :

Electrical characteristics :
- supply voltage : 230V ±15% 50/60 Hz
- outputs : 4 changeovers contact
μ 16 A - 250 V AC1
μ 3 A - 250 V cos φ = 0.6
1000 W incandescent lighting
- power consumption : 20 VA
- protection degree : IP20
- insulation class : II
Functional characteristics :
- accuracy : ± 1sec. / day at 20 °C
- operating reserve : lithium battery,
total of five years.
Environment :
Operating temperature : -10 to +50 °C
Storage temperature : -20 to +60 °C
Connection tunnel terminals :
2
flexible : 0,5 to 2,5 mm
2
rigid : 0,5 to 4 mm
Dimensions : 5 modules

Electrical connections :

L
N
OFF
A
A
B
11 12 13 14 15 16 17 18 19 20
C
D
B
C D
C
reset
D
EG470
A B
enter on auto off
1 2 3 4 5 6 7 8 9 10
Warranty
GB
A warranty period of 24 months is offered on hager products,
from date of manufacture, relating to any material of manufac-
turing defect. If any product is found to be defective it must be
returned via the installer and supplier (wholesaler). The warran-
ty is withdrawn if :
- after inspection by hager quality control dept the device is
found to have been installed in a manner which is contrary to
IEE wiring regulations and accepted practice within the industry at
the time of installation.
- the procedure for the return of goods has not been followed.
Explanation of defect must be included when returning goods.
