hager EG210 Instructions For Use

_________________________________________________________________________
http://waterheatertimer.org/Hagar-timers-and-manuals.html
™ §
2 channels time switch -
daily cycle
User instruction
A
ON
ON B
au to
OFF nu
OFF ma
t
re se
r
en te
on
of f
EG210
Working principle : Time setting :
The EG 210 is a time switch for the automatic
control of electrical loads.
It is fully programmable with a maximum of 20
program steps, to be divided between the two
channels.
The front cover is sealable preventing
unauthorised access after completion of
programming.
Warning : at the beginning of use, please
reset the device in order to clear the memory
before programming.
on
This is achieved by using a pen to push the
reset button.
1. Move mode selector to
Presentation :
2. Input time with buttons "+" and "-".
Important :
The clock starts when exiting the time setting mode.
2
3
Programming channel A :
ON ON
1
A 4
B
auto
manu
on
reset
enter
off
5 6 7 8
on
Display :
Œ
time

circuit status of channel A (ON or OFF)
Ž
1. Move mode selector to "A".
circuit status of channel B (ON or OFF)
2. Input switching time with buttons "+" and "-".
3. Input the type of switching with button "on/off"
(for the first action ON is automatically proposed).
Buttons :
 4. Enter this program step with button "enter".
Mode selector : to select one of the
Program additional time settings by repeating
following modes :
steps 2 to 4.
time setting
A programming channel A
Important :
B programming channel B
To activate the program, move mode selector to
auto running mode
"auto".
manu manual override

"on/off" : chooses whether the circuit
Programming channel B :
is on or off
‘
Move mode selector to "B".
"+" and "-" : changes settings
’ Same way of programming as channel A.
"enter" : to confirm
“
Important :
"reset"
To active the program, move mode selector to "auto".
Running Auto mode
This mode is the current displaying mode.
It does not allow any modification.
Move mode selector to "auto".
Display of the time and the state of the two channels.
1
To check your program on channel
A or B :
1. Move mode selector to "A" or "B".
2. Press the "enter" key repeatedly to display
the different program steps (switching
time, and state of the channel ON or OFF).
A
B
auto
manu
To modify or delete a program
step on channel A or B :
reset
enter
off
on
off
1. Move mode selector to "A" or "B".
2. Press "enter" repeatedly and select the
program step to modify or to delete.
ON 3. Modify :
A
B - switching time with keys "+" or "-",
auto
- state of the channel with key "on/off".
manu
To delete a program step, modify switching
time with keys "+" and "-", until display --:--
(between 23:59 and 00:00).
4. Confirm with the "enter" key.
reset
enter
off
To override the output :
Important : the override will be identical on
the two channels (channels A and B
"ON""ON" or channels A and B "OFF""OFF").
Permanent override :
on
off
1. Move mode selector to "manu".
2. Select the state of the outputs with key
"on/off".
To switch back to automatic mode, move
mode selector to "auto".
Timed override :
ON ON
on
enter
off
ON
A
B
auto
1. Move mode selector to "manu".
manu
2. Select the state of the outputs with key
"on/off".
3. Input with key "+" and "-" the override dura-
tion : from 1 to 23 hours by steps of 1 hour.
reset
Then from 1 to 27 days by steps of 1 day.
enter
4. Move mode selector to "auto".
The state indication is flashing. This means a
timed override. Return to the initial program
after the duration.
To cancel the timed override :
ON ON
on
enter
off
1. Move mode selector to "manu".
2. Press key "-" or "+" until display -h.
3. Move mode selector to "auto" to switch
back to automatic mode.
ON ON
A
B
auto
manu
To reset the time switch :
Press "reset" to clear the program.
reset
enter
Technical specifications :
Electrical characteristics :
- supply voltage : 230V +10/-15% 50Hz
- outputs : 2 changeover contact
μ 16A - 250V AC1.
μ 3A - 250V cos w = 0,6
1000 W incandescent lighting
A
B
- power consumption : 1 VA
auto
manu - protection degree : IP20
- insulation class : II
Functional characteristics :
- accuracy : ± 1sec. / day at 20 °C
reset
- operating reserve : lithium battery,
total of three years.
Environment :
Operating temperature : -10 to +50 °C
Storage temperature : -10 to +50 °C
Connection tunnel terminals :
2
flexible : 0,5 to 2.5 mm
2
rigid : 0,5 to 4 mm
Dimensions : 3 modules (3x17,5mm)
Electrical connections :
L
N
A
B
auto
manu 7 8 9 10 11 12
B
reset
EG210
A
1 2 3 4 5 6
Warranty
GB
A warranty period of 24 months is offered on hager products,
from date of manufacture, relating to any material of manufac-
turing defect. If any product is found to be defective it must be
returned via the installer and supplier (wholesaler). The warranty
is withdrawn if :
- after inspection by hager quality control dept the device is
found to have been installed in a manner which is contrary to
IEE wiring regulations and accepted practice within the industry at
the time of installation.
- the procedure for the return of goods has not been followed.
Explanation of defect must be included when returning goods.
