hager EGN100AU Installation Manual

EGN100AU
Multi-function Time Switch 1 Channel
For additional information, please
scann the QR code.
Hager Mood
01
EGN100AU
02
L
N
4
01 01
Installation manual
z
Multi-function Time Switch 1 Channel Bluetooth
Manuel d'installation
a
Horloge multifonction 1 voie Bluetooth
Manual de instalação
t
Programador horário multifunções 1 canal
Bluetooth
Manual de instalación
r
Interruptor temporizador multifunción 1 canal
Bluetooth
Safety instructions
z
Electrical devices may only be installed
and assembled by a qualified electrician in
accordance with the relevant installation
standards, guidelines, regulations, directives,
safety and accident prevention regulations
of the country.
Failure to comply with these instructions
may result in damage to the device, fire or
other hazards.
Not suitable for controlling SELV loads.
Complies with
IMDA Standards
These instructions are an integral part of
DA101847
the product and must be retained by the
end user.
Presentation
C1/FCT (key and LED) used for:
1
- output control;
- Bluetooth
BLE/CFG (key and LED) used for:
1
2
- Bluetooth
- resetting parameters.
Override input or exception
3
Brightness sensor
4
2
Function
The EGN100AU time switch is a clock with
weekly and annual electronic programming
that automatically controls different loads.
Examples of applications: street lighting, neon
signs, shop windows, monuments, facades etc.
The integrated astronomical clock can be
set to switch loads according to sunset and
sunrise times.
The connection of an EEN002 / EEN003 twi-
light sensor (optional) makes it possible to
switch the loads according to brightness.
Programming is performed with a mobile
terminal via Bluetooth
configuration application (iOS and Android)
available as a free download.
Main features
1 5
− Product delivered with updated time and
3 7
day (Paris)
− Programming by application via Blue-
tooth
®
automatic daylight savings time change,
3
2 6
astronomical mode,
4 8
programming by day or group of days,
100 program steps On, Off, pulses
®
®
reset.
®
activation and deactivation (BLE);
®
technology using the
®
technology:
− Permanent overrides On or Off
− Temporary overrides On or Off
− Exceptions (temporary, permanent or
delayed) can be activated remotely using
a push button
®
Electrical installation
®
Danger
Electric shock when live parts are
touched!
An electric shock can lead to
death!
•
Isolate all connection cables be-
fore working on the device and
cover any live parts in the area!
•
Connect the device as shown in the
circuit diagram (Fig. 02)
Initial set-up
Bluetooth
To program and set the clock with a mobile
terminal, the Bluetooth
activated.
Each time the BLE key is pressed (> 2 s) the
function is enabled or disabled.
BLE LED status / Operation
off Bluetooth
Bluetooth
Blue
Bluetooth
connected
Blue
Table 1: LED operation and status
Configuration application
To set the clock, use the application and per-
form the installation as described below.
Download the application from App
1
Store (IOS) or Google Playstore (An-
droid) with your mobile device.
Install the configuration application.
2
Check that Bluetooth
3
(see Initial set-up/ BLUETOOTH).
Pair your mobile terminal and your
4
clock via the Bluetooth
Program your product via the application.
5
To do this, follow the application in-
structions to configure the clock.
Settings via the configuration application:
Settings for the use of your clock are available
via the application as settings of:
− date and time
− astronomical clock
− wired input
− daylight savings time change
− twilight sensor
Operation
LED status - Override - Exception
Information
Bluetooth
function must be
®
disabled
®
enabled
®
® assembled and
is enabled
®
application.
®
must be disconnected.
®
