Figure B–12: Tighten Velcro Around Battery.
•
Connect the external battery pack to the D
inserting the power plug protruding from the battery to the power
jack in the top of the D

Mounting to a Surveyor Tripod

The Environmental
Enclosure may be
mounted to a standard
surveyor tripod equipped
⁄
5
with a "-11 threaded
8
stud. Mounting the
Enclosure on a tripod is
useful when doing
outdoor site monitoring.
Figure B-13 shows the
Environmental Enclosure
mounted on a surveyor
tripod.
!
Do not place the Environmental Enclosure in direct contact
with the ground. The bottom of the Environmental Enclosure
contains an exhaust port that may allow water to enter the
enclosure, resulting in damage to the D
Setting-Up
T monitor
UST RAK
Figure B–13: Enclosure
Mounted on a Tripod.
C a u t i o n
T monitor by
UST RAK
.
monitor
T
UST RAK
.
61
