4.3 Trigger

The radar transmits and receives microwave energy when you pull
the trigger . To measure the flow velocity, pull and release the trigger .
The radar will continue to transmit even though the trigger is now
released . See Section 6 .2 - Taking a Measurement .
4.4 Mounting Configurations
The radar is designed for hand-held operation . Optionally, you can
mount it to a standard camera tripod .

5. Operating Modes

The MENU and SEL buttons on the SVR™ control panel lets you review
and change settings . The radar gun will remember the settings you
last set when it is turned off and will power up with them .

5.1 Menu

You can use the factory default settings or you can select your own
settings . To select a setting, repeatedly press the MENU button until
the setting you want to change appears . Then release the MENU
button and press the SEL (select) button to advance through the
selections for that setting . When you have made your selection,
release the button and your new settings will be in effect . If neither
MENU or SEL is pressed after 2 seconds, the radar gun will return
to normal operating mode, capturing whatever settings you have
selected to that point . Table 5 .1 shows the menu setting choices .
• bl = Backlight (on/off )
• C = Cosine Adjustment(0º to 60º in increments of 5º)
• U = Units of measure (European meters-per-second or
USA feet-per-second)
• A =Angle (reporting only)
• SEN = Sensitivity (1-10 with 10 being maximum sensitivity)
• HL = High or Low speed ranges
• SEr = Serial Protocols (Sr1 and Sr2)
• SEr U = Serial Update rate (100, 300, 500, 800 or 999 ms)
