Summary of Contents for Global American 3308170
- Page 1 User’s Manual Single B oard Computer 3308170 Version 1 .0 , Month 2008...
- Page 2 Copyrights This manual is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer. In general, the manufacturer will not be liable for any direct, indirect, special, incidental or consequential damages arising from the use of inability to use the product or documentation, even if advised of the possibility of such...
- Page 3 Introduction Chapter 1 Introduction Chapter 1 - Introduction...
-
Page 4: Packing List
Introduction Packing List 3308170 .” Embedded Board x Driver CD x Quick Installation Guide x CPU Cooler 90 x 66 x 27.8mm (L x W x H) x ATX Power cable ATX main power connector (2x0 pins) to EmCORE-i96... -
Page 5: Specifications
Introduction 1.9 Specifications Form Factor .” Embedded Board mPGA 78 Socket for Intel® Core™ 2 Duo Processor, up to FSB 800MHz Chipset Intel ® GME96 + Intel ® ICH8M x 200-pin SO-DIMM socket Up to 2GB DDR II System Memory /667MHz SDRAM Mobile Intel®... -
Page 6: Board Dimensions
Introduction 3.38 95.2 1.10 Board Dimensions 101.96 Layout Top View 7.32 30.48 45.98 16.8 Unit:mm... -
Page 7: Layout Bottom View
Introduction Layout Bottom View 3.38 95.2 101.96 Unit:mm 7.32 30.48 45.98... -
Page 8: Installing The Cpu
Introduction 1.11 Installing the CPU The processor socket comes with a screw to secure the CPU. As showing in the picture as bellow, loose the screw first before inserting the CPU. Place the CPU into the socket by making sure the notch on the corner of the CPU corresponding with the notch on the inside of the socket. -
Page 9: Installing The Memory
Introduction 1.12 Installing the Memory Side notch Latch knob Latch claw Latch section Latch arm Polarizing key To install the Memory module, locate the Memory SO-DIMM slot on the board and perform as below: Adjust the socket polarizing key and the board key to the same direction. Insert the board obliquely. -
Page 10: Heat Sink Installation
Introduction 1.13 Heatsink Installation Put the heatsink on 3308170 , and screw it on in the direction of the board. Insert four screws (No. ) downward into the holes and turn them tightly. Verify the direction is correct (No. 2) and plug the FAN connector into CPUF connector. - Page 11 Introduction 1.14 Heatsink Dimensions 15.75 14.5 30.25...
-
Page 12: Installation
Installation Chapter 2 Installation Chapter 2 - Installation... -
Page 13: Block Diagram
Installation 2.1 Block Diagram Intel® CPU 533/800MHz Analog R.G.B. 533/667MHz Intel® 1 x 200pin DDRII Memory Bus SO-DIMM socket GME965 LVDS LVDS USB I/F 6 x USB PCI Bus 1 x Mini PCI Intel® Serial ATA I/F 2 x SATA ICH8M IDE ATA I/F 1 x IDE... -
Page 14: Jumpers And Connectors
Installation 2.2 Jumpers and Connectors IDE1 CON1 SATA1 SATA2 LPT1 9 10 ATX1 MINIPCI1 23 24 JBAT1 USB3 KBM1 LAN2 COM2 RES1 VGA1 200pin DDR II SO-DIMM Socket CFD1... -
Page 15: Jpwr1: At/Atx Power Mode
Installation Jumpers JP1, JP3: COM Port Power Special Support (8), (21) Connector type: 2.mm pitch x pin header. Voltage Standard Signal for Pin-9 (default) +2V JRS1: COM2 RS-232/422/485 Mode Select (12) The onboard COM2 port can be configured to operate in RS-422 or RS-485 modes. -
Page 16: Jvlcd1: Lcd Panel Voltage Select
Installation JVLCD1: LCD Panel Voltage Select (16) The voltage of LCD panel could be selected by JVLCD in +V or +.V. Connector type: 2. mm pitch x pin header Voltage +.V (Default) JP2: Compact Flash Select (17) Connector type: 2.mm pitch x2 pin header. Pin 1-2 Function Select Short... -
Page 17: Jbat1: Clear Cmos Setup
Installation JBAT1: Clear CMOS Setup (27) If the board refuses to boot due to inappropriate CMOS settings here is how to proceed to clear (reset) the CMOS to its default values. Connector type: 2.mm pitch x pin header Mode Keep CMOS (Default) Clear CMOS You may need to clear the CMOS if your system cannot boot up because you forgot your password, the CPU clock setup is incorrect, or the CMOS... - Page 18 Installation Connectors IDE1: IDE Connector (1) An IDE drive ribbon cable has two connectors to support two IDE devices. If a ribbon cable connects to two IDE drives at the same time, one of them has to be configured as Master and the other has to be configured as Slave by setting the drive select jumpers on the drive.
-
Page 19: Lvds1: Lvds Lcd Connector
Installation LVDS1: LVDS LCD Connector (2) The LVDS connector supports 2-bit or 8-bit LVDS. VDD could be selected by JVLCD in +V or +.V. Connector type: DF--0DP-.2V Description Description TX2CLK+ TXCLK+ TX2CLK- TXCLK- TX2D0+ TXD0+ TX2D0- TXD0- TX2D+ TXD+ TX2D- TXD- TX2D2+ TXD2+... - Page 20 Installation SATA1, 2: Serial ATA Connectors (4), (5) The CPU board on board supports two SATA II connectors, second generation SATA drives transfer data at speeds as high as 00MB/s, twice the transfer speed of first generation SATA drives. The SATA drives can be configured in a RAID 0, RAID 1 or RAID 10 configuration.
-
Page 21: Smbus1: External Smbus Connector
Installation SMBUS1: External SMBUS Connector (9) Connector type: 2.mm pitch x box wafer connector. Description Data Clock DIO1: Digital I/O Connector (10) DIO is a 8-bit DIO connector that supports -bit In/ -bit Out. Connector type: 2.00 mm pitch 2x pin header Description Description DIO... -
Page 22: Lpt1: Parallel Port Connector
Installation LPT1: Parallel Port Connector (11) Connector type: 2.00mm pitch 2x0 pin header. Description Description STROBE# AFD# PTD0 Error# PTD INIT# PTD2 SLIN# PTD PTD PTD N/C (Key) PTD6 Busy PTD7 ACK# Select LPT1 can be configured as a connector floppy disk drive (FDD) interface through BIOS setup. -
Page 23: Com1: Rs-232 Connector
Installation COM1: RS-232 Connector (13) Connector type: 2.00mm pitch 2x pin header. Description Description DCD# DTR# DSR# RTS# CTS# CPUF1: CPU Fan Power Connector (15) CPUF is -pin header for the system fan. The fan must be a +2V fan. Description +2V FAN_Detect... -
Page 24: Jfrt1: Switches And Indicators
Installation JFRT1: Switches and Indicators (19) It provides connectors for system indicators that provides light indication of the computer activities and switches to change the computer status. Connector type: 2. mm pitch 2x pin header Description Description RESET+ RESET- POWER LED+ POWER LED- HDD LED+ HDD LED-... -
Page 25: Atx1: Atx Power Supply Connector
Installation USB1/ USB2: USB Connector (20), (23) Connector type: 2.00mm pitch 2x pin header. USB/ USB2 supports two USB 2.0 w/ 80MB/s by pin header Description Description USBD- USBD- USBD+ USBD+ N/C (Key) ATX1: ATX Power Supply Connector (22) The ATX power supply has a single lead connector with a clip on one side of the plastic housing. -
Page 26: Lan1: Fast Ethernet Connector
Installation LAN1: Fast Ethernet Connector (24) Connector type: 2.0mm pitch 2x pin header Description Description TX_MDI0+ TX_MDI0- RX_MDI+ MDI2+ MDI2- RX_MDI- MDI+ MDI- N/C (Key) MINIPCI1: MiniPCI slot (25) AUDIO1: Front Panel AUDIO Connector (26) Connect a tape player or another audio source to the light blue Line-in connector to record audio on your computer or to play audio through your computer’s sound chip and speakers. -
Page 27: Com2: Rs-232 Connector
Installation COM2: RS-232 Connector (28) Connector type: D-Sub 9-pin male. Description Description DSR# DCD# RTS# CTS# DTR# VGA1: CRT Connector (29) Connector type: D-Sub -pin female. Description Description GREEN BLUE VDDAT HSYNC VSYNC VDCLK RES1: Reset Switch (30) -
Page 28: Kbm1: Keyboard & Mouse
Installation KBM1: Keyboard & Mouse (31) Mini-Din Keyboard & Mouse connector Description KB Data MS Data KB Clock MS Clock Note: KBM supports PS/2 keyboard directly, and PS/2 mouse supported with the additional PS/2 -to-2 cable in standard packing. LAN2: 10/100/1000 RJ-45 (32) LAN2 supports 0/00/00 Mbps Fast Ethernet LAN2 USB3: Double Stack USB Type A Connector (33) -
Page 29: Installation Instructions
Installation CFD1: Compact Flash II Socket (34) Connector type: 50-pin compact flash connector Pin Description Pin Description CF_Detect PDD PDD PDD PDD2 PDD PDD PDD6 PDD PDD7 PDD PDCS# PDCS# PDIOR# PDIOW# PIDEIRQ CSEL# IDERST# PIORDY PDA2 PDDREQ PDA PDDACK# PDA0 HD_LED# PDIAG#... - Page 30 Appendix Chapter 4 Appendix Chapter 4 - Appendix...
-
Page 31: I/O Port Address Map
Appendix 4.1 I/O Port Address Map Each peripheral device in the system is assigned a set of I/O port addresses which also becomes the identity of the device. The following table lists the I/O port addresses used. Address Device Description 00000000 - 0000000F DMA Controller 00000080 - 0000009F... -
Page 32: Interrupt Request Lines (Irq)
Appendix 00000A0 - 00000A7 Hardware Monitor 00000CF8 PCI Configuration Address 00000CFC PCI Configuration Data 4.2 Interrupt Request Lines (IRQ) Peripheral devices use interrupt request lines to notify CPU for the service required. The following table shows the IRQ used by the devices on board. Level Function IRQ 0... -
Page 33: Bios Memory Mapping
Appendix 4.3 BIOS memory mapping Address Device Description 00000h - 9FFFFh DOS Kernel Area A0000h, BFFFFh EGA and VGA Video Buffer (28KB) C00000h - CFFFFh EGA/VGA ROM D0000h - DFFFFh Adaptor ROM E00000h - FFFFFh System BIOS... - Page 34 Any advice or comments about our products and service, or anything we can help you with please don’t hesitate to contact us. We will do our best to support your products, projects and business. Address: Global American, Inc. 17 Hampshire Drive Hudson, NH 03051 Telephone: Toll Free (U.S. Only) 800-833-8999...
