- Page 1 Owner's Manual Paramount 65X GRAPHIC LAMINATION PRODUCTS Please read and retain these instructions. To register your product, please go to www.royalsovereign.com www.royalsovereign.com Royal Sovereign International Inc.
-
Page 2: Table Of Contents
CONTENTS 1. Introduction∙ ∙ ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 2. Safety Precautions∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 4 4. Installation∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5 5. Product Identification∙ ∙ ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙7 6. Control Panel∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 8 7. Using Foot Pedal∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 9 8. Loading Film∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 9 9. Threading Film∙ ∙ ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 9 9.1 Decaling∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 10 9.2 Mounting∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙... -
Page 3: Introduction
Graphic Lamination Products Model Paramount 65X 1. IN TRODUCTION Thank you for choosing a Royal Sovereign laminator. It has been designed and manufactured to provide years of continuous service. For complete operating and maintenance information please read this manual thoroughly. Upon receipt of your laminator, please inspect the box, the machine and all other contents for shipping damage. -
Page 4: Safety Precautions
8. Ensure the unit is turned o , cooled, and unplugged from the outlet prior to moving and/or repairing. 9. Keep out of reach of children. 10. Only Royal Sovereign authorized maintenance and service technicians should make repairs. 11. Do not attempt to laminate items that exceed total recommended material thickness for the unit 12. -
Page 5: Installation
Once the laminator is in place, lock the casters into position. Always unlock the casters when moving to a different location. ELECTRICAL REQUIREMENTS Royal Sovereign recommends that a licensed electrician ensures proper power installation to your laminator in accordance with electrical codes in your area. - Page 6 4. INCLUDED WITH LAMINATOR Thoroughly inspect the parts and the unit. It is imperative that any missing parts are reported and a claim is filed with the reseller immediately upon receipt of shipment. Part Name Quantity Picture Laminator Owner's Manual Spare Motor Fuse - FUSE(50T) (6.3A) Spare Main Power Fuse - FUSE(65TS)
-
Page 7: Product Identification∙ ∙ ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙7
Paramount 65X 5. PRODUCT IDENTIFICATION Film Tension Knob Shaft Feeder Shaft Release Liner Air Intake Emergency Switch Knob Speed Control Roller Button Safety Sensor Pressure Gauge Table Front Pressure Regulating Valve Foot Pneumatic Toggle Foot Switch Door Lock... -
Page 8: Control Panel
6. CONTROL PANEL To change the mode from cold to heat assist. Temperature for heat assist on upper roller is Heat max 122°F/50°C. Reverse To reverse the rollers, press and hold the button. Rotate the knob to control the roller’s speed from Speed 0 to 19.7 ft/min. -
Page 9: Using Foot Pedal
Repeat to stop the rollers. 8. LOADING FILM Royal Sovereign films are wound with the adhesive side facing the inside of the roll (adhesive in). Loading films to upper and lower film shafts: Remove the upper and lower film shafts from the machine and load the films (Center the upper and lower films on the shaft). -
Page 10: Decaling
9.1. Decaling 1. Turn the power switch on (“I” position). The Power switch is located on the rear left side of the unit. 2. Complete the steps as in the “LOADING FILM” section 3. Pull the top lm down to the bottom of the craft paper/mounting lm. 4. -
Page 11: Troubleshooting
Paramount 65X 11. TROUBLESHOOTING Sympton Cause Possible Solution a. Plug the power cord into appropriate outlet. a. Power plug is not plugged in. b. Power switch is in “0” (O b. Put the power switch to the “I” Machine will not turn on: position. -
Page 12: Specifications
12. SPECIFICATIONS Description Paramount 65X Power Supply AC100V,120V,220~240V,50/60Hz Power Consumption 1450W Maximum Laminating Width 65"(1650mm) Max. Material Diameter(Film) Ø 7.8” (200mm) Maximum Laminating Speed 19.7 ft./min. (6m/min) Ready Time <40min Heating Method Hot Roller Maximum Temperature 122°F(50°C) Film Core 3" Auto Grip Roller Nip 1.8”... -
Page 13: Warranty
13. WARRANTY Royal Sovereign International warrants the equipment sold is free from defects in material and workmanship for a period of One (1) year for Parts and Labor from the date of installation, excluding lamination rollers which are warranted for Six (6) months.
