Integration of 3
rd
Several 3 party devices can be connected to the HDS Live. The
applications are displayed on separate panels or integrated with
other panels.
A device connected to the NMEA 2000 network should
automatically be identified by the system. If not, enable the feature
from the advanced option in the System settings dialog.
rd
The 3 party device is operated by using menus and dialogs as on
other panels.
This manual does not include specific operation instructions for any
rd
3 party device. For features and functionality, refer to the
documentation included with the 3

SmartCraft VesselView integration

When a compatible Mercury Marine VesselView product or
VesselView Link is present on the NMEA 2000 network, the engines
can be monitored and controlled from the unit.
When the feature is also enabled in the advanced settings features
dialog:
• A Mercury icon is added to the home page - select it to display
the engine instrument panel.
You can customize which data is displayed on the info panel.
Refer to "Info panels" on page 102.
• A Mercury settings dialog is added - use this dialog to change
engine settings.
• Mercury and Vessel Control buttons are added to the control bar:
- Selecting the Mercury button displays engine and vessel data.
- Selecting the Vessel button opens the engine controller.
When the features are enabled, the display may prompt the user for
some basic configuration information.
For more information, refer to the VesselView manual or engine
supplier.

Suzuki engine integration

If a Suzuki C-10 gauge is available on the NMEA 2000 network, the
engines can be monitored from the unit.
Integration of 3 party
Manual
rd
party devices
rd
party device.
devices| HDS Live Operator
