BACnet Objects

5 BACnet Objects
5.1.1 Analog Input- and Output Objects
Control the frequency converter from the BACnet network using 'objects'. The various types of 'objects' and their descriptions
are shown in the following tables. In the following tables all available objects are shown. The availability of objects depends on
the mounting of the B and/or C options.
Object_Name
ID Default name
AI:0 Analog Input 53
AI:1 Analog Input 54
AI:2 Analog In X30/11
AI:3 Analog In X30/12
AI:4 Analog In X42/1
AI:5 Analog In X42/3
AI:6 Analog In X42/5
Table 5.1 Analog Inputs Object Map
Object_Name
ID Default name
Terminal 42 Output Bus
AO:0 Control
AO:1 Pulse out #27 Bus Control
AO:2 Pulse out #29 Bus Control
Terminal X30/8 Output Bus
AO:3 Control
AO:4 Analog Output X42/7
AO:5 Analog Output X42/9
AO:6 Analog Output X42/11
Table 5.2 Analog Outputs
®
VLT HVAC Drive Native BACnet Operating Instructions
Present_Value
Parameter
1662
1664
1675
1676
1830
1831
1832
Present_Value
Parameter Unit
653 %
593 %
595 %
663 %
2643 V
2653 V
2663 V
®
MG.14.C1.02 - VLT is a registered Danfoss trademark
Unit Option
%
%
% MCB 101
% MCB 101
V MCB 109
V MCB 109
V MCB 109
Writeable Cmd.able
x x
x x
x x
x x
x x
x x
x x
5
Timeout Option
x
x
x
x MCB 101
x MCB 109
x MCB 109
x MCB 109
