Astria Fireplaces Gamma26ZTN Installation And Operation Instructions Manual

Vent-free compact dual-flame fireplace

Advertisement

Quick Links

P/N 126882-01 REV. B 04/2018
P126882-01
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home,
where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the
rating plate. This appliance is not convertible for use with other gases.
This is an unvented gas-fi red heater. It uses air (oxygen) from the room in which it is installed. Provisions
for adequate combustion and ventilation air must be provided. Refer to Air for Combustion and Ventilation
section on Page 6 of this manual.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Do not store or use gasoline or other fl ammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fi re department.
- Installation and service must be performed by a qualifi ed installer, service agency or the gas supplier.
Installation and Operation Instructions
Vent-Free Compact Dual-Flame Fireplace
Models
PFS
®
US
Report No. F09-123
Gamma26ZTN
Gamma26ZTP
Gamma26ZMN
Gamma26ZMP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Gamma26ZTN and is the answer not in the manual?

Questions and answers

Summary of Contents for Astria Fireplaces Gamma26ZTN

  • Page 1 Installation and Operation Instructions Vent-Free Compact Dual-Flame Fireplace P/N 126882-01 REV. B 04/2018 Models Gamma26ZMN Gamma26ZTN Gamma26ZMP Gamma26ZTP ® P126882-01 Report No. F09-123 INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home, where not prohibited by local codes.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety ..............2 Cleaning and Maintenance ........ 24 Product Identifi cation ........... 5 Wiring Diagram ..........25 Local Codes............5 Troubleshooting ..........26 Product Features ..........5 Specifi cations ............ 30 Unpacking............6 Replacement Parts ..........30 Hood Assembly............
  • Page 3 SAFETY Continued Young children should be carefully IMPORTANT: Read this owner’s supervised when they are in the same manual carefully and completely room with the appliance. When us- before trying to assemble, operate or ing the hand-held remote accessory service this fi replace. Improper use (Remote-Ready Models Only), keep of this fi...
  • Page 4 SAFETY Continued off. If heated, the vapors from these products 1. WARNING: This appliance is only for may create a white powder residue within use with the type of gas indicated on burner box or on adjacent walls or furniture. the rating plate.
  • Page 5: Product Identifi Cation

    PRODUCT IDENTIFICATION Left Side Fireplace Fireplace Cabinet Cabinet Hood Hood Screen Logs Right Igniter Side Button Front Remote Control Igniter Button (Optional) Control Knob Control Knob Figure 1 - Vent-Free Compact Dual Flame Fireplace LOCAL CODES Install and use fi rebox with care. Follow all *Available from: local codes.
  • Page 6: Unpacking

    UNPACKING 3. Make sure your fi replace includes one 1. Remove fi replace and hood from carton. hardware packet. Log is wrapped and inside fi replace. Do not remove at this time. 4. Check all items for any shipping damage. If damaged, promptly inform dealer where 2.
  • Page 7: Air For Combustion And Ventilation

    AIR FOR COMBUSTION AND VENTILATION Unusually tight construction is defi ned as construction where: WARNING: This appliance shall a. walls and ceilings exposed to the out- not be installed in a room or space side atmosphere have a continuous unless the required volume of indoor water vapor retarder with a rating of one combustion air is provided by the perm (6 x 10...
  • Page 8 AIR FOR COMBUSTION AND VENTILATION Continued DETERMINING FRESH-AIR FLOW 4. Compare the maximum Btu/Hr the space can support with the actual amount of Btu/ FOR FIREBOX LOCATION Hr used. Determining if You Have a Confi ned or _______ Btu/Hr (maximum the space can Unconfi...
  • Page 9 AIR FOR COMBUSTION AND VENTILATION Continued The space in the previous example is a confi ned space because the actual Btu/Hr used is more 12" than the maximum Btu/Hr the space can sup- port. You must provide additional fresh air. Your Ventilation Ventilation Grills Grills Into...
  • Page 10: Installation

    INSTALLATION IMPORTANT: Vent-free fi replaces add mois- NOTICE: This appliance is intended ture to the air. Although this is benefi cial, for supplemental heating. Use this installing fi replace in rooms without enough heater along with your primary ventilation air may cause mildew to form from too much moisture.
  • Page 11 INSTALLATION Continued NOTE: If desired, purchase a four-sided pe- B. Clearances from the top of the fi replace rimeter trim kit for built-in installations. See opening to the ceiling should not be less Accessories, Page 30. than 36". C. For mantel clearances, see Figure 10 on FIREPLACE CLEARANCES Page 12.
  • Page 12 INSTALLATION Continued 2. If installing GA3450TA blower accessory, the equipment shutoff valve. The fl exible do so at this time. Follow instructions gas line must be the last item installed on included with blower accessory. the gas piping. NOTE: If not installing blower accessory, 4.
  • Page 13 INSTALLATION Continued NOTICE: If your installation does WARNING: Do not allow any not meet the minimum clear- combustible/noncombustible ances shown, you must do one materials to overlap the fi rebox of the following: front facing. • raise the mantel to an accept- able height WARNING: Do not allow •...
  • Page 14 INSTALLATION Installation must include an equipment shutoff valve, union and plugged 1/8" NPT tap. Locate Continued NPT tap within reach for test gauge hook up. CONNECTING TO GAS SUPPLY NPT tap must be upstream from heater (see Figure 13). WARNING: This appliance IMPORTANT: Install equipment shutoff valve requires a 45°...
  • Page 15 INSTALLATION 4. Check all gas connections for leaks. See Checking Gas Connections, below. Feed Continued fl exible gas line into fi replace. Make sure We recommend that you install a sediment the entire fl exible gas line is in fi replace. trap in supply line as shown in Figure 13, Page 13.
  • Page 16 INSTALLATION propane/LP supply to equipment shutoff valve for propane/LP (see Figures 17 or Continued 18). Apply noncorrosive leak detection fl uid to all joints. Bubbles forming show a leak. CAUTION: Make sure exter- 4. Correct all leaks at once. nal regulator has been installed between propane/LP supply and PRESSURE TESTING FIREPLACE GAS CONNECTIONS...
  • Page 17 INSTALLATION Continued OPTIONAL WIRELESS HAND-HELD OPTIONAL WALL MOUNTED REMOTE CONTROL ACCESSORIES THERMOSTAT - GWMT1 Remote-Ready Models Only (MRC (Remote-Ready Models Only) and TRC) WARNING: Read and fol- Installing Receiver low installation instructions. 1. Disconnect jumper wires from the control Installation should be done by valve (see Figure 19).
  • Page 18 INSTALLATION Continued 7. Install base onto wall with provided WARNING: Do not con- screws. nect the thermostat to a power 8. Move temperature adjustment back and source. Electrical shock and/or forth to ensure the bimetal is free from a fi re hazard will occur. restrictions.
  • Page 19: Operation

    INSTALLATION Continued INSTALLING LOG SET AND SCREE 1. Remove log packaging material and Shoulder discard packaging. Gently place log over Screw burner (see Figure 24). Do not allow log to contact fl ame. If fl ame contacts log, soot will be created. 2.
  • Page 20 OPERATION Continued THERMOSTAT-CONTROLLED MODELS 2. Make sure equipment shutoff valve is fully NOTE: If pilot goes out, repeat steps 3 open. through 7. This fi replace has a safety inter 3. Turn control knob clockwise to the lock system. Wait one (1) minute for system OFF position.
  • Page 21 OPERATION Continued THERMOSTAT-CONTROLLED MODELS MANUAL LIGHTING NOTE: Your fi replace and thermostat blower will not turn on and off at the same time. PROCEDURE The fi replace may run for several minutes 1. Follow steps 1 through 5 under Lighting before the blower turns on.
  • Page 22 OPERATION Continued REMOTE-READY MODELS 1. STOP! Read the safety information, 10. To leave pilot lit and shut off burners only, Page 20. turn control knob clockwise to PILOT posi- 2. Make sure equipment shutoff valve is fully tion. If using optional hand-held remote, open.
  • Page 23 OPERATION Continued REMOTE-READY MODELS OPTIONAL GWMT1 WALL OPTIONAL HAND-HELD MOUNTED THERMOSTAT REMOTE OPERATION Set the temperature adjustment on wall ther- NOTE: All remote control accessories must mostat to the desired setting. The thermostat be purchased separately (see Accessories, has been electronically calibrated at the fac- Page 30).
  • Page 24: Inspecting Burners

    INSPECTING BURNERS Bright yellow burner fl ame; fl ame will be blue next to burner Check pilot fl ame pattern and burner fl ame patterns often. PILOT FLAME PATTERN Figure 33 shows a correct pilot fl ame pattern. Figure 34 shows an incorrect pilot fl ame pat- tern.
  • Page 25: Wiring Diagram

    CLEANING AND MAINTENANCE Continued We also recommend that you keep the burner hole about 2" from where the pilot flame tube and pilot assembly clean and free of dust comes out of the pilot assembly (see Figures and dirt. To clean these parts we recommend 38 or 39 depending on model).
  • Page 26: Troubleshooting

    TROUBLESHOOTING WARNING: Turn off and unplug fi replace and let cool before servicing. Only a qualifi ed service person should service and repair fi replace. CAUTION: Never use a wire, needle or similar object to clean ODS/pilot. This can damage ODS/pilot unit. NOTE: All troubleshooting items are listed in order of operation.
  • Page 27 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY ODS/pilot lights but flame 1. Control knob not fully 1. Press in control knob fully goes out when control knob pressed in is released 2. Control knob not pressed in 2. After ODS/pilot lights, keep long enough control knob pressed in 30 seconds...
  • Page 28 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Slight smoke or odor during 1. Residues from manufac- 1. Problem will stop after a few initial operation turing processes and log hours of operation curing 2. Not enough air 2. Check burner for dirt and debris.
  • Page 29 TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Fol- low the gas supplier’s instructions.
  • Page 30: Specifi Cations

    • Inlet Gas Pressure (in. of water): • Inlet Gas Pressure (in. of water): Max - 14" W.C., Min* - 11" W.C. Max - 14" W.C., Min* - 11" W.C. Gamma26ZTN Gamma26ZMN • Rating (Variable): 17,000/26,000 Btu/Hr • Rating (Variable): 17,000/26,000 Btu/Hr •...
  • Page 31 ACCESSORIES Continued Black Platinum PERIMETER TRIM KIT Cat. No. F1816, Model GAB6094 - Black WALL-MOUNT ON/OFF SWITCH Cat. No. F1817, Model GAP6094 - Platinum Cat. No. F0245, Model GWMS2 For all models. Optional three-sided perimeter trim For all models. Allows the gas log heater to be kit for recessed installations (when unit is on the turned on and off with a wall switch.
  • Page 32: Parts

    PARTS FIREBOX MODELS GAMMA26ZMP, GAMMA26ZMN, GAMMA26ZTN AND GAMMA26ZTP WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP. Use of non-approved parts can result in poor performance and safety hazards. Cat. No.
  • Page 33 PARTS FIREBOX MODELS GAMMA26ZMP, GAMMA26ZMN, GAMMA26ZTN AND GAMMA26ZTP This list contains replaceable parts used in your fi replace. When ordering parts, follow the instructions listed under Replacement Parts on Page 29 of this manual. PART NO. DESCRIPTION QTY. Outer Casing Top •...
  • Page 34 PARTS THERMOSTAT MODELS GAMMA26ZTP AND GAMMA26ZTN Astria.us.com 126882-01B...
  • Page 35 PARTS THERMOSTAT MODELS This list contains replaceable parts used in your fi replace. When ordering parts, follow the instructions listed under Replacement Parts on Page 29 of this manual. PART NO. DESCRIPTION J4502 Dual Burner • • J3614 Injector (0.0595) •...
  • Page 36 PARTS REMOTE-READY MODELS GAMMA26ZMN AND GAMMA26ZMP Natural Gas Only Astria.us.com 126882-01B...
  • Page 37 PARTS REMOTE-READY MODELS This list contains replaceable parts used in your fi replace. When ordering parts, follow the instructions listed under Replacement Parts on Page 29 of this manual. PART NO. DESCRIPTION QTY. J4502 Dual Burner • • J3614 Injector (0.0595) •...
  • Page 38 NOTES ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________...
  • Page 39: Warranty

    Innovative Hearth Products ® Astria Brand Gas Fireplace Limited Lifetime Warranty THE WARRANTY Innovative Hearth Products ("IHP") Limited Lifetime Warranty warrants your Astria ® brand gas fireplace ("Product") to be free from defects in materials and workmanship at the time of manufacture. The product body, firebox and barrier carry the Limited Lifetime Warranty. Ceramic glass carries the Limited Lifetime Warranty against thermal breakage only.
  • Page 40 Astria.us.com Record the following important information about your appliance: Appliance model number Appliance serial number Date appliance was Installed Type of gas appliance uses Dealer name IHP reserves the right to make changes at any time, without notice, in design, materials, specifi...
