Technical Specifications; Configuring Netway8G For Network Connection; Factory Default Settings; Network Settings - Altronix NetWay8G Installation Manual

Parameter
No. of Ports
Input Power Requirements
Indicators
Environmental Conditions
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of an insulated DANGEROUS VOLTAGE within the product's enclosure that may
be of sufficient magnitude to constitute an electric shock .
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying
the appliance .

Configuring NetWay8G for Network Connection

Please be sure to visit altronix.com for latest firmware and installation instructions

Factory Default Settings

•• IP Address:
• User Name:
• Password:
1 . Set the static IP address for the laptop to be used for programming to the same network IP address as the
NetWay8G . The default address of the NetWay8G is 192 .168 .168 .168, E .I . 192 .168 .168 .200 .
2 . Connect one end of the network cable to the network jack on the NetWay8G and the other to the network
connection of the laptop .
3 . Open a browser on the computer and enter "192 .168 .168 .168" into the address bar . A dialog box
Authentication Required will appear requesting both user name and password .
Enter the default values here . Click on the button labeled Log In .
4 . The status page of the NetWay8G will appear . Click on the tab labeled Network Settings . This will open
the Network Setting screen . In this screen the MAC Address of the NetWay8G module will be found along
with the Network Settings and Email Settings .

Network Settings:

In the IP Address Method field select the method that the IP Address for the NetWay8G will be obtained
(STATIC or DHCP), then follow the appropriate steps .

Static:

A . IP Address: Enter the IP address assigned to the NetWay8G by the network administrator .
B . Subnet Mask: Enter the Subnet of the network .
C . Gateway: Enter the TCP/IP gateway of the network access point (router) being used . (gateway configuration
is required to properly receive emails from the device)
D . HTTP Port: Enter the HTTP port number assigned to the NetWay8G module by the network administrator
to allow remote access and monitoring . The default inbound port setting is 80 . HTTP is not encrypted and
unsecure . Even though HTTP can be used for remote access, it is recommended primarily for use with
LAN connections .
E . HTTPS Port: Enter the HTTPS port number assigned to the NetWay8G module by the network administrator
to allow remote access and monitoring . The default inbound port setting is 443 . Being encrypted and more
secure, HTTPS is highly recommended for remote access .
F . Click the button labeled Submit Network Settings . A dialog box will display "New network settings will
take effect after the server is rebooted" . Click OK .
- 6 -

Technical Specifications:

Description
Eight (8) PoE+ Ports (10/100/1000 Mbps) .
115VAC, 60Hz, 3 .25A or 230VAC, 50/60Hz, 2 .0A .
Port Status LEDs .
Operating Ambient Temperature:
Relative Humidity:
Storage Temperature:
Operating Altitude:
CAUTION: To reduce the risk of electric shock do not open
enclosure . There are no user serviceable parts inside . Refer servicing
to qualified service personnel .
192 .168 .168 .168
admin
admin
– 20ºC to 40ºC (– 4ºF to 104ºF) .
85%, +/– 5% .
– 20ºC to 70ºC (– 4ºF to 158ºF) .
– 304 .8 to 3,048m .
NetWay8G
