Line Inputs - Solid State Logic A16.D16 User Manual

A16.D16, A32 and D64 User Guide
Line Inputs
Parameter
Maximum Input Level
Frequency Response
Usable Dynamic Range
THD+N
Sample Rates
Resolution
Line Outputs
Parameter
Maximum Output Level
Output Impedance
Frequency Response
Usable Dynamic Range
Crosstalk
THD+N
Output Symmetry
Sample Rates
Resolution
Measurement Parameters
Sample Rate:
Operating Level:
Reference frequency:
Value Notes
+24 dBu 10 kΩ load
± 0.1 dB -1 dBFS, 20 Hz – 20 kHz
> 116 dB 0 dBFS, A-weighted filter, 22 kHz
bandwidth
Typically >117 dB
< 0.005 % 20 Hz – 20 kHz, -1 dBFS, 22 kHz
bandwidth
Typically < 0.004%
44.1, 48, 88.2
or 96 kHz
24 bit
Value Notes
+24 dBu 600 Ω / 10 kΩ load
< 50 Ω
± 0.3 dB -1 dBFS, 20 Hz – 20 kHz
> 116 dB 0 dBFS, A-weighted filter, 22 kHz
bandwidth
Typically >117 dB.
< -90 dB 20 Hz – 20 kHz, 0 dBFS
< -105 dB 1 kHz, 0 dBFS
< 0.01 % 20 Hz – 20 kHz, -1 dBFS. 22 kHz
bandwidth
Typically < 0.004%
> 40 dB 20 Hz – 20 kHz
Typically > 50 dB
44.1, 48, 88.2
or 96 kHz
24 bit
96 kHz
+24 dBu = 0 dBFS
1 kHz (unless stated otherwise)
