Appendix C – Performance Specifications
Mic/Line Inputs
Parameter
Gain Range
Maximum Input Level
Frequency Response
Equivalent Input Noise
Usable Dynamic Range
Input Impedance
CMRR
Crosstalk
THD+N
Phantom Power (Mic
Input)
Pad (Mic Input)
Operating Levels
Sample Rates
Resolution
Measurement Parameters
Sample Rate:
Operating Level:
Mic input termination:
Mic Mode Gain:
Reference frequency:
Value Notes
+26 to +70 dB Mic mode, 0 dBFS, 0.1 dB gain step size
-4 to +30 dB Line mode, 0 dBFS, 0.1 dB gain step size
-4 to +40 dB Mic mode with pad engaged
+27.5 dBu 30 dB Pad inserted
Mic mode, 20 Hz – 20 kHz (@48kHz)
± 0.2 dB
Typically ± 0.1 dB
Mic mode, 70 dB gain, A-weighted filter,
< -123 dB 22 kHz bandwidth.
Typically -124 dB
Mic mode, 0 dBFS, A-weighted filter,
> 115 dB 22 kHz bandwidth.
Typically 116 dB.
2.3 kΩ / 10 kΩ Mic / Line. Selectable per channel
> 70 dB Mic mode, 20 Hz – 20 kHz, 0 dBu
> 90 dB Mic mode, 1 kHz, 0 dBu
20 Hz – 20 kHz
> -75 dB
1 kHz
> -90 dB
< 0.01 % Mic mode, 20 Hz – 20 kHz, -1 dBFS,
22 kHz bandwidth.
+48 V ±4 V
Selectable per channel
10 mA
30 dB Selectable per channel
+24, +22, +20,
+18, +15 dBu
44.1, 48, 88.2
or 96 kHz
24 bit
96 kHz
+24 dBu = 0 dBFS
150Ω
26 dB (unless stated otherwise)
1 kHz (unless stated otherwise)
