System Specifications

Processor

The following table specifies the Intel Atom Z5xxP/PT processor performance. For details about the
processor, see Core
Parameter (note 2)
Processor operating frequency (commercial)
Processor operating frequency (industrial)
Front side bus clock
Front side bus width
Notes:
2. The VEC7000 Development Kit operates at 1.6 GHz, commercial temperature.

Power

Power Supply

The Vector accepts the main power input on J10, page 30. For details about the power supply
architecture, see Power Supply
Symbol
Input Voltage
VIN
Output Voltage
V3.3S
BTN_ONOFF#
V
IH
V
IL
R
PU
V
PU
Notes:
3. BTN_ONOFF# includes a pull-up resistor to 5V "always on".

Power Consumption

The following table lists estimated power consumption for the Vector.
Symbol
P
Run

Electrical

This section provides electrical specifications for the Vector.

Embedded Controller

The embedded controller provides two A/D inputs on header J23, page 34. For descriptions of these
signals, see A/D Inputs, page
Symbol
A/D Input
V
IN
110124-7000A
Processor, page 13.
Architecture, page 22.
Parameter
Supply voltage
Normal operating power
High-level input voltage
Low-level input voltage
Pull-up resistance (note 3)
Parameter
Run mode power
2
20 and I C Bus, page 17.
Parameter
Analog input voltage
A/D sample resolution
System Specifications
Min Typ. Max
1.1 1.6
1.33
400 533
64
Min Typ. Max
7 12 25
3.135 3.3 3.465
2.5 5
1.0
10
5
Min Typ. Max
7
Min Typ. Max
5
10
Units
GHz
GHz
MHz
bit
Units
V
V
V
V
kΩ
V
Units
W
Units
V
bit
37
