J12: Ethernet

Board connector: RJ-45 socket with LEDs, Pulse Engineering JK0-0036NL
Mating connector: RJ-45 plug
Socket J12 provides a direct connection to a Gigabit Ethernet network. The socket includes two
Ethernet LEDs, page

J13: VGA Display Output

Board connector: 2x10 shrouded header, 2 mm, Hirose DF11-20DP-2DSA
Mating connector: Hirose DF11 series socket
Header J13 provides an analog RGB output to support a standard VGA monitor. For further details,
see VGA Display Output, page 19.
Name
Pin
1
HSYNC_OUT
2
PTPB
3
GND
4
GND
5 VSYNC_OUT
6 CBVS_VIDEO
7 GND
8 GND
9 GREEN_OUT
10 SVIDEO_C
11 GND
12 GND
13
RED_OUT
14 SVIDEO_Y
15
GND
16
GND
17 BLUE_OUT
18 DDC_SDA
19 GND
20 DDC_SCL

J14: SATA Drive

Board connector: 7-pin SATA header, 0.050-inch, Molex 67800-5002
Mating device: 2.5-inch SATA disk drive
Header J14 supports a 2.5-inch SATA disk drive. For a description of the external memory interfaces
available on the Vector, see
Name
Pin
1 GND
2 SATA_TX+
3 SATA_TX-
4 GND
5 SATA_RX-
6 SATA_RX+
7
GND
110124-7000A
28 and built-in magnetics. For further details, see Ethernet, page 17.
Type
O
O
P
P
O
O
P
P
O
O
P
P
O
O
P
P
O
IO
P
O
External Memory Interfaces, page 14.
Type
P
O
P
P
Connectors, Switches, and Indicators
Description
Horizontal sync
Ground
Ground
Vertical sync
CBVS (option)
Ground
Ground
Green data
S Video C (option)
Ground
Ground
Red data
S Video Y (option)
Ground
Ground
Blue data
2
DDC I C data
Ground
2
DDC I C clock
Description
Ground
SATA Transmit
Ground
I SATA Receive
Ground
