6.5 Unit Left Access

1
2
Rev. 01
05/27/2016
3

Figure 6 UNIT RIGHT ACCESS

NUMBER NAME
1 DIRTY FILTER STATIC PRESSURE TIP
2 RETURN AIR TEMP/HUM SENSOR
3 BLOWER MOTOR
4 SUCTION ACCUMULATOR
5 HUMIDIFIER
Page 15 of 42
