If the unit is provided with condensate overflow sensor, the unit mounted control panel
includes a condensate probe module. The condensate probe sensor shall be shipped loose for
field installation. Condensate probe sensor shall be located underneath the unit where water
may collect to sense any condensate overflow. To check the operation of the probe, submerse
it in a cup of water. The condensate alarm should energize.
If the unit is provided with sensing cable type leak detection system, use specific manual
provided by the manufacturer to install the complete system. Alarm relay dry contact from
sensing cable type leak detection system can be connected to the digital input for condensate
alarm of unit controller. Use 24VAC power from the unit terminal block for this alarm input.
8.0
INSTALLATION
8.1 Room Preparation
The room should be well insulated and sealed for water vapor. Door gaps and cracks
should also be sealed to minimize outside air from introducing into the insulated room.
8.2 Location Considerations
Unit can sit on an elevated flooring while remains fully accessible. Floor stand or other
support maybe used to further support the unit.
After moving the unit to the desired location, the system needs to be leveled and
anchored to the floor as directed by the building design engineer, typically using wedge
anchors. Prior to anchoring the unit to the floor, verify locations for Chilled Water Supply
and Chilled Water Return line connections, drain line connection as well as the electrical
power input locations are matching with unit location requirement. Proper electrical
supply power is an absolute necessity as the unit is designed specifically for the
requirements on the nameplate. All knock-out shall be provided by others in the field.
The unit is designed with draw-thru air pattern with negative pressure inside. The
condensate drain connection must be installed with a proper p-trap as without it, the
condensate water will not drain thus possibly causing water carry over into the air space.
The p-trap must be calculated as per
of the p-trap, verify trap operation by running the system blowers at full speed and
Rev. 01
05/27/2016
Figure 8: P-TRAP SCHEMATIC
Page 17 of 42
below. After installation
