Noise Figure and Gain Measurements
Setting
Noise Figure
Gain
xxx
Intermediate Values Tab
The Intermediate Values tab shows the noise figure and gain uncertainty values (dB). These values change
based on the parameters set in the Uncertainty Calculator display and the noise measurement results.
Setting
Uncertainty for Noise Figure
Uncertainty for Gain
Mismatch Source-SA
Mismatch Source-DUT
Mismatch DUT-SA
xxx
226
Description
Shows the standard uncertainty for the noise figure measurement. This value also
reflects the uncertainty tolerance for noise figure based on the confidence level
(conversion factor) set by the user in the Display.
Shows the standard uncertainty for the gain measurement. This value also reflects the
uncertainty tolerance for gain based on the confidence level (conversion factor) set by
the user in the Display.
Description
Shows the uncertainty for three components of the noise figure measurement.
Shows the uncertainty for three components of the gain measurement.
Shows the error between the noise source and the spectrum analyzer.
Shows the error between the noise source and the device under test (DUT).
Shows the error between the device under test (DUT) and the spectrum analyzer.
Uncertainty Calculator Settings
