MODULE 2 ZONES PLANCHER
MODULO A 2 ZONE PER IMPIANTO A PAVIMENTO
HYDRAULIK - MODUL FÜR 2 ZONEN FUSSBODEN
Mars 2009
(Etiquette signalétique)
M2Z P
2-ZONE FLOOR MODULE
MÓDULO 2 ZONAS SUELO
(HEIZUNG ODER KÜHLUNG)
MÓDULO 2 ZONAS SOALHO
NOTICE
D'INSTALLATION
INSTALLATION
INSTRUCTION
MANUALE
D'INSTALLAZIONE
MANUAL
DE INSTALACIÓN
AUFSTELLUNGS-
HANDBUCH
INSTRUÇÕES
DE INSTALAÇÃO
10 11 465 - F.GB.I.E.D.P - 02
F
GB
I
E
D
P
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Technibel M2Z P
Summary of Contents for Technibel M2Z P
- Page 1 DE INSTALACIÓN AUFSTELLUNGS- (Etiquette signalétique) HANDBUCH INSTRUÇÕES DE INSTALAÇÃO M2Z P MODULE 2 ZONES PLANCHER 2-ZONE FLOOR MODULE MODULO A 2 ZONE PER IMPIANTO A PAVIMENTO MÓDULO 2 ZONAS SUELO HYDRAULIK - MODUL FÜR 2 ZONEN FUSSBODEN (HEIZUNG ODER KÜHLUNG) MÓDULO 2 ZONAS SOALHO...
-
Page 2: Table Of Contents
MARKING This product marked conforms to the essential requirements of the Directives: - Low voltage no. 2006/95/EC. - Electromagnetic Compatibility no. 89/336 EEC, modified 92/31 and 93/68 EEC. CONTENTS 1 - General ..........2 2 - Presentation . -
Page 3: Presentation
2 - PRESENTATION 2.1 - DESCRIPTION 1 - Housing 10 - Circulator terminal strip, zone 1 2 - Mixing cylinder 11 - Circulator terminal strip, zone 2 3 - Automatic air vent valve 12 - Control board, zone 1 4 - Motorised, 3-way valve, zone 1 13 - Control board, zone 2 5 - Motorised, 3-way valve, zone 2 14 - Outlet water sensor, zone 1... -
Page 4: Installation
3 - INSTALLATION • Protection rating of the module: IP 31. • The module must be installed in a sheltered location. • Remove the module's front panel (6 screws on the sides). • Secure the module to the wall. See the position of the 4 mounting holes in paragraph 2.2. 4 - CONNECTIONS 4.1 - HYDRAULIC CONNECTION •... - Page 5 Control box With built-in ambient temperature sensor. To be installed in zone 1. 2-ZONE FLOOR MODULE A BUS Board, zone 2 Board, zone 1 Heating board HEATING MODULE Water Water temperature, temperature, zone 1 zone 2 Possible accessory Ambient Ambient 70250065 temperature, temperature,...
-
Page 6: Start-Up
4.2.3 - ZONE BOARD CONNECTION DETAIL Water temperature sensor Valve contact input (floor outgoing line) Pump control Zone ambient temperature sensor Zone addressing micro-switch 230 Vac Valve control 4.2.4 - CABLE ROUTING 230 V power supply BUS A Zone ambient sensor(s) P 5 - START-UP IMPORTANT NOTE... -
Page 7: Maintenance Instructions
5.3 - OPERATION • Check circulator operation in the generator and the operation of the 2 circulators of the module. Adapt the speed of the circulators in order to respect the flow rates. For the generator, refer to the corresponding installation manual. Note: When the system is off, operation can be forced by changing the parameterization: - of zone 1 (accelerator on and control valve open) with parameter 65,... -
Page 8: Electrical Diagram
Temperature ambiance sensor (zone 2) Circulator, zone 1 Circulator, zone 2 Circuit breaker, zone 1 Circuit breaker, zone 2 ELECTRICAL DIAGRAM - M2Z P 10 05 807 - 03 Power supply 230V / 1 / 50 Water probe Water probe... - Page 12 Par souci d'amélioration constante, nos produits peuvent être modifiés sans préavis. Due to our policy of continuous development, our products are liable to modification without notice. Per garantire un costante miglioramento dei nostri prodotti, ci riserviamo di modificarli senza preaviso. En el interés de mejoras constantes, nuestros productos pueden modificarse sin aviso prévio.
