Carrier UVLCC1LP Installation Instructions Manual

Accessory Ultraviolet (UV) Germicidal Lamp
1 & 2 Lamp Models—115-v & 208/230-v
NOTE: Read the entire instruction manual before starting the installation.
This symbol → indicates a change since the last issue.
WARNING: EYE & SKIN BURN HAZARD
Failure to follow this warning could result in personal injury.
This unit contains high energy ultraviolet C-band (UVC) germicidal lamps which can cause serious temporary eye and skin
irritation. Never expose unprotected eyes or skin to the UVC light.
Installation and servicing of air-conditioning equipment can be hazardous due to system pressure and electrical components. Only trained and
qualified service personnel should install, repair or service HVAC equipment.
Untrained personnel can perform basic maintenance functions such as changing lamps. All other operations should be performed by trained service
personnel. When working on air-conditioning equipment, observe precautions in the literature, tag and labels attached to the unit or accessory, and
all other safety precautions that may apply.
Recognize safety information. This is the safety-alert symbol
to the potential for personal injury.
Understand the signal words DANGER, WARNING, and CAUTION. These words are used with the safety-alert symbol. DANGER identifies the
most serious hazards which will result in severe personal injury or death. WARNING signifies a hazard which could result in personal injury or
death. CAUTION is used to identify unsafe practices which would result in minor personal injury or product and property damage. NOTE is used
to highlight suggestions which will result in enhanced installation, reliability, or operation.
Follow all safety codes. Wear safety glasses and work gloves. Have a fire extinguisher available if needed. Read these instructions thoroughly and
follow all warnings or cautions attached to the unit. Consult local building codes and National Electrical Code (NEC) for special requirements.
Before proceeding with installation, inspect thoroughly for shipping damage. Notify shipper immediately if any damage is found. Check for proper
clearances of moving parts.
The qualified installer or agency must use factory-authorized kits or accessories when modifying this product. Refer to the individual instructions
packaged with the kits or accessories when installing.
00001398
Form:
Installation Instructions
Fig. 1–Two Lamp Model UV Lamp

SAFETY

. When you see this symbol on the unit and in instructions or manuals, be alert
Printed in U.S.A.
FEB-2018
UV Lamp
C03009
Catalog No. IM-UVLCR-01
