Carrier Infinity GAPAB Installation Instructions Manual

_rn to the Experts[
Installation Instructions
NOTE: Read the entire instruction manual before starting the
install.
TABLE OF CONTENTS
PAGE
INTRODUCTION .................................... 1
HOW IT WORKS .................................... 1
SAFETY CONSIDERATIONS .......................... 1
APPLICATION CONSIDERATIONS .................... 2
INSTALLATION ................................... 3-6
START-UP AND OPERATION ......................... 7
MAINTENANCE ................................. 7 - 8
TROUBLESHOOTING ................................ 9
SPECIFICATIONS AND DIMENSIONS ................. 10
WARRANTY ....................................... 11
INTRODUCTION
Congratulations for selecting the Infinity T., Air Purifier for your
home comfort system! The Infinity" Air Purifier is proven to
remove and kill airborne germs and allergens, including viruses,
bacteria, and mold spores. The Infinity T" Air Purifier is a
cornerstone of Carrier's Healthy Home Solutions for providing
healthier, cleaner air in your home.
HOW IT WORKS
The Infinity _" Air Purifier provides extremely high filtration
performance while killing captured contaminants, including
viruses, bacteria, and mold spores. The Infinity" Air Purifier
treats the entire air-stream through a state of the art, three-stage
process, exclusive to Carrier.
In stage one, the particles are electrically charged by a
precision-point ionization array as they enter the Infinity _" Air
Purifier.
In stage two, the charged particles are electrically attracted to the
air purification cartridge, which is located within an electric field.
In stage three, captured particles are killed by electrical current
flow and ion bombardment.
The Infinity :'' Air Purifier is CSA certified for shock and
electrical fire hazard only.
La Infinity" Air Purifier certification CSA vise uniquement les
risques de choc electrique et.
Fig. 1 - GAPAB Unit
A06377
SAFETY CONSIDERATIONS
Improper installation, adjustment, alteration, service,
maintenance, or use can cause explosion, fire, electrical shock or
other conditions which may cause personal injury or property
damage. Consult a qualified installer, service agency, or your
distributor or branch for information or assistance. The qualified
installer or agency must use factory authorized kits or accessories
when modifying this product. Refer to the individual instructions
packaged with the kits or accessories when installing.
Follow all safety codes. Wear safety glasses and work gloves.
Have a fire extinguisher available. Read these instructions
thoroughly and follow all warning or cautions attached to the
unit. Consult local building codes and National Electrical (;ode
(NEC) for special requirements.
It is important to recognize safety information. This is the
safety-alert symbol Z_. When you see this symbol on the unit
and in instructions or manuals, be alert to the potential for
personal injury. Understand the signal words DANGER,
WARNING, and CAUTION. These words are used with the
safety-alert symbol. DANGER identifies the most serious
hazards which will result in severe personal injury or death.
WARNING signifies hazards which could result in personal
injury or death. CAUTION is used to identify unsafe practices
which may result in personal injury or product and property
damage. NOTE is used to highlight suggestions which will result
in enhanced installation, reliability, or operation.
