CONTENTS

SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . 1

PRE-INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . 1

Moving and Storage . . . . . . . . . . . . . . . . . . . . . . . . 1
Rigging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-23

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Uncrating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Unit Positioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Unit Isolation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Refrigerant and Chilled Water
Piping Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Refrigerant Piping . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Chilled Water Piping . . . . . . . . . . . . . . . . . . . . . . . 17
Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Fan Motors And Drives . . . . . . . . . . . . . . . . . . . . . 18
Power Supply And Wiring . . . . . . . . . . . . . . . . . . . 19
Connecting Ductwork . . . . . . . . . . . . . . . . . . . . . . 22
Return-Air Filters . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23-39
Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Fan Motor Lubrication . . . . . . . . . . . . . . . . . . . . . . 23
Fan Shaft Bearings . . . . . . . . . . . . . . . . . . . . . . . . . 23
Centering Fan Wheel . . . . . . . . . . . . . . . . . . . . . . . 24
Fan Shaft Position Adjustment . . . . . . . . . . . . . . 24
Individual Fan Wheel Adjustment . . . . . . . . . . . 24
Fan Belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Fan Rotation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Fan Pulley Alignment . . . . . . . . . . . . . . . . . . . . . . . 25
Pulley And Drive Adjustment . . . . . . . . . . . . . . . . 25
Condensate Drains . . . . . . . . . . . . . . . . . . . . . . . . . 25
Return-Air Filters . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Coil Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Cleaning Cooling Coil . . . . . . . . . . . . . . . . . . . . . . 25
Cleaning Insulation . . . . . . . . . . . . . . . . . . . . . . . . 25
Replacing Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Start-Up Checklist . . . . . . . . . . . . . . . . CL-1,CL-2
SAFETY CONSIDERATIONS
Installing, starting up, and servicing this equipment can
be hazardous due to system pressures, electrical components
and equipment location (elevated structures, etc.).
Only trained, qualified installers and service mechanics
should install, start up, and service this equipment.
Untrained personnel can perform basic maintenance func-
tions such as cleaning coils, and cleaning and replacing
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Book 1 4
PC 111
Tab
3c 2e
Installation, Start-Up and
Service Instructions
Page
Catalog No. 534-053
Printed in U.S.A.
Packaged Air-Handling Units
filters. All other operations should be performed by trained
service personnel.
When working on the equipment, observe precautions in
the literature and on tags, stickers, and labels attached to the
equipment.
• Follow all safety codes.
• Wear safety glasses and work gloves.
• Use care in handling, rigging, and setting bulky
equipment.
Be sure all power to equipment is shut off before per-
forming maintenance or service. More than one discon-
nect may be present.
PRE-INSTALLATION
Moving and Storage —
storage site, use a fork truck. Do not stack units more than
2 high during storage. If unit is to be stored for more than
2 weeks before installation, choose a level, dry storage site
free from vibration. Do not remove plastic wrap or skid from
unit until final installation.
Rigging —
All 40RM Series units can be rigged by us-
ing the shipping skid. Units are shipped fully assembled. Do
not remove shipping skids or protective covering until unit
is ready for final placement; damage to bottom panels can
result. Use slings and spreader bars as applicable to lift unit.
INSTALLATION
General —
Allow 2
1
ft at front and side of unit for
2
service clearance and airflow. For units equipped with an econo-
mizer, refer to the accessory installation instructions for ad-
ditional clearance requirements. Be sure floor, wall, or ceil-
ing can support unit weight (Tables 1A-1F). See
Fig. 1A-1C for dimensions.
Uncrating —
Move unit as near as possible to final lo-
cation before removing shipping skid.
Remove metal banding, top skid, and plastic wrap. Ex-
amine unit for shipping damage. If shipping damage is
evident, file claim with transportation agency. Remove base
skid just prior to actual installation.
Check nameplate information against available power
supply and model number description in Fig. 2.
Accessories —
Refer to instructions shipped with each
accessory for specific information.
Form 40RM-9SI
Pg 1
40RM
40RMQ
40RMS
50/60 Hz
To transfer unit from truck to
11-95
Replaces: 40RM-1SI

Advertisement

Table of Contents
loading

Summary of Contents for Carrier 40RM

  • Page 1 Do not remove plastic wrap or skid from unit until final installation. Rigging — All 40RM Series units can be rigged by us- ing the shipping skid. Units are shipped fully assembled. Do not remove shipping skids or protective covering until unit is ready for final placement;...
  • Page 2 Hot Water Coil, In (MPT) Hot Water Coil, Out (MPT) Condensate (PVC) FILTERS Quantity...Size (in.) Access Location LEGEND TXV — Thermostatic Expansion Valve *Units are shipped without refrigerant charge. Table 1A — 40RM Physical Data, English ⁄ 1...15 1...15 1...15 2...15 2400 3000 4000...
  • Page 3 Table 1B — 40RMQ Physical Data, English UNIT 40RMQ NOMINAL CAPACITY (Tons) OPERATING WEIGHT (lb) Base Unit with TXV Plenum FANS Qty...Diam. (in.) Nominal Airflow (cfm) Airflow Range (cfm) Nominal Motor Hp (Standard Motor) 208/230-1-60 208/230-3-60 and 460-3-60 575-3-60 230-3-50, 400-3-50 Motor Speed (rpm) 208/230-1-60 208/230-3-60 and 460-3-60...
  • Page 4: 40Rms Physical Data

    UNIT 40RMS NOMINAL CAPACITY (Tons) ⁄ OPERATING WEIGHT (lb) Base Unit Plenum FANS Qty...Diam. (in.) 1...15 Nominal Airflow (cfm) 3000 Airflow Range (cfm) 2250-3750 Nominal Motor Hp (Standard Motor) 208/230-1-60 208/230-3-60 and 460-3-60 575-3-60 230-3-50 and 400-3-50 Motor Speed (rpm) 208/230-1-60 1725 208/230-3-60 and 460-3-60...
  • Page 5 Hot Water Coil, In (MPT) Hot Water Coil, Out (MPT) Condensate (PVC) FILTERS Quantity...Size Access Location LEGEND TXV — Thermostatic Expansion Valve *Units are shipped without refrigerant charge. Table 1D — 40RM Physical Data, SI 1...381 1...381 1...381 2...381 1133 1604 1888 2360 850-1416 1203-2006 1416-2360 1770-2949 2124-3539 2831-4719 3539-5899 4247-7079 0.97...
  • Page 6 Table 1E — 40RMQ Physical Data, SI UNIT 40RMQ NOMINAL CAPACITY (kW) OPERATING WEIGHT (kg) Base Unit with TXV Plenum FANS Qty...Diam. (mm) Nominal Airflow (L/s) Airflow Range (L/s) Nominal Motor kW (Standard Motor) 208/230-1-60 208/230-3-60 and 460-3-60 575-3-60 230-3-50, 400-3-50 Motor Speed (r/s) 208/230-1-60 208/230-3-60 and 460-3-60...
  • Page 7 UNIT 40RMS NOMINAL CAPACITY (kW) OPERATING WEIGHT (kg) Base Unit Plenum FANS Qty...Diam. (mm) 1...381 Nominal Airflow (L/s) 1416 1062- Airflow Range (L/s) 1770 Nominal Motor kW (Standard Motor) 208/230-1-60 1.79 208/230-3-60, 460-3-60 1.79 575-3-60 1.49 230-3-50, 400-3-50 1.79 Motor Speed (r/s) 208/230-1-60 28.8 208/230-3-60, 460-3-60...
  • Page 8 • Right Side: 2 ft, 6 in. (762 mm) • Left Side: 2 ft, 6 in. (762 mm) • Local codes or jurisdiction may prevail. 4. Liquid piping not supplied by Carrier. 5. Duct flange is factory supplied and field installed.
  • Page 9 • Right Side: 2 ft, 6 in. (762 mm) • Left Side: 2 ft, 6 in. (762 mm) • Local codes or jurisdiction may prevail. 4. Liquid piping not supplied by Carrier. 5. Duct flange is factory supplied and field installed. 6. 40RMQ016 and 40RMS units may re- quire alternate or additional field-fabricated piping access holes.
  • Page 10 • Right Side: 2 ft, 6 in. (762 mm) • Left Side: 2 ft, 6 in. (762 mm) • Local codes or jurisdiction may prevail. 4. Liquid piping not supplied by Carrier. 5. Duct flange is factory supplied and field installed. 6. 40RMS units may require alternate or additional field-fabricated piping ac-...
  • Page 11: Unit Positioning

    *YC and WD option codes for all 034 size units and 008, 010 units with 208/230-1-60 power designate standard motor and high-static drive. NOTE: See the following table for the sizes available for each unit. UNIT 40RM 40RMQ 40RMS Unit Positioning —...
  • Page 12: Unit Isolation

    40RMQ016 unit requires additional field-fabricated piping access holes. See Fig. 4, which also lists recommended knock- outs and access holes to use for each 40RM and 40RMQ unit size. Recommended fittings are listed in Table 3. The sensor bulb capillary tubes must be routed from the TXVs inside the unit through one of the piping access holes.
  • Page 13 Do NOT mount the sensor on a trapped por- tion of the suction line. 40RM Series evaporator coils have a face-split design. En- sure that lower circuit of coil is first on/last off when con- nected to the condensing unit and/or system controls. See Fig.
  • Page 14 PART NO. 38AQS SIZE (in.) ⁄ P504-8084S ⁄ P504-8165S ⁄ P504-8084S ⁄ P504-8085S *Available from Carrier Replacement Components Division. Fig. 8 — Filter Drier Requirements — 38AQS012/40RMQ012 and 38AQS016/40RMQ016 Heat Pump Systems NOZZLE Qty...Part No. 1...E5 1...C6 1...C6 2...E4 2...E4 2...E5 2...E6...
  • Page 15 ACCESS UNIT HOLE NO.* 40RM 40RM 40RMQ 40RMS 008-012 40RM 40RMQ 40RM 40RMS 014-024 *See Fig. 4 for access hole location by number. †Fittings are listed in order from header or tee stub connection out to access hole in corner support post.
  • Page 16 ACCESS UNIT HOLE NO.* 40RM 40RMQ 40RM 40RM *See Fig. 4 for access hole location by number. †Fittings are listed in order from header or tee stub connection out to access hole in corner support post. Table 3 — Fitting Requirements (cont)
  • Page 17: Chilled Water Piping

    final position. Knockouts are provided in the unit corner posts for 40RM and 40RMQ refrigerant piping; additional field-fabricated ac- cess holes are required for 40RMS chilled water piping. See Fig.
  • Page 18: Condensate Drain

    Condensate Drain — Install a trapped condensate drain line to unit connection as shown in Fig. 10. The unit drain connection is a PVC stub. See Fig. 11. Some areas may re- quire an adapter to connect to either galvanized steel or copper pipe.
  • Page 19: Power Supply And Wiring

    ⁄ -in. ring terminal. The 40RM, 40RMQ and 40RMS size 007-016 units (ex- cept 40RM016 with YC or WD option) that have motors wired for 460-v, 3-ph, 60 Hz operation can be field-converted to FAN SCROLL...
  • Page 20 UNIT V*-PH-HZ 208/230-1-60 208/230-3-60 460-3-60 40RM 575-3-60 230-3-50 400-3-50 208/230-1-60 208/230-3-60 40RM 460-3-60 40RMQ 40RMS 575-3-60 230-3-50 400-3-50 208/230-1-60 208/230-3-60 460-3-60 40RMS 575-3-60 230-3-50 400-3-50 208/230-3-60 40RM 460-3-60 40RMQ 575-3-60 40RMS 230-3-50 400-3-50 208/230-3-60 460-3-60 40RM 40RMS 575-3-60 230-3-50 400-3-50...
  • Page 21 UNIT V*-PH-HZ 208/230-1-60 208/230-3-60 40RM 460-3-60 575-3-60 208/230-3-60 40RM 460-3-60 40RMQ 575-3-60 40RMS 230-3-50 400-3-50 208/230-3-60 460-3-60 40RMS 575-3-60 230-3-50 400-3-50 208/230-3-60 40RM 460-3-60 40RMQ 575-3-60 40RMS 230-3-50 400-3-50 208/230-3-60 460-3-60 40RM 40RMS 575-3-60 230-3-50 400-3-50 208/230-3-60 40RM 460-3-60 40RMQ...
  • Page 22: Connecting Ductwork

    (vac) 40RMS 007-034 Connecting Ductwork — Refer to the Carrier Sys- tem Design Manual for the recommended design and layout of ductwork. Figure 15 shows recommended duct connec- tion to units with 2 fans. DISCHARGE CONNECTIONS — Duct flanges are factory supplied;...
  • Page 23: Installation

    START-UP Before starting unit, check the following and correct as necessary: • Is unit solidly supported? • Is fan adjusted for speed and pulley alignment? • Are pulleys, motor, and bearings securely mounted? • Are there any loose parts that will rattle or vibrate? •...
  • Page 24: Centering Fan Wheel

    Centering Fan Wheel — If fan and fan shaft assem- bly are not properly centered, blades may scrape against scroll or may create an objectionable whistling noise. It may be necessary to adjust individual fan wheels or move entire fan shaft.
  • Page 25: Fan Pulley Alignment

    Fig. 20 — Fan Rotation Fan Pulley Alignment — Align as follows: 1. Loosen setscrews on pulleys. 2. Align pulleys visually and tighten setscrews on fan pul- ley to lock it in place. 3. Use the methods shown in Fig. 21 to check proper pulley alignment.
  • Page 26 Table 8A — Fan Motor Data, Standard Motor — English 40RM 40RM 40RMQ UNIT 40RMS 208/230-1-60 Speed (rpm) 1725 1725 Frame (NEMA) Shaft Dia (in.) ⁄ 208/230-3-60 and 460-3-60 Speed (rpm) 1725 1725 Frame (NEMA) Shaft Dia (in.) ⁄ 575-3-60...
  • Page 27 Table 8C — Fan Motor Data, Standard Motor — SI 40RM 40RM 40RMQ UNIT 40RMS 208/230-1-60 Speed (r/s) 28.75 28.75 Shaft kW 0.97 1.79 Frame (NEMA) Shaft Dia (mm) 15.9 15.9 208/230-3-60 and 460-3-60 Speed (r/s) 28.75 28.75 Shaft kW 1.79...
  • Page 28 Table 9A — Standard Drive Data, 60 Hz — English 40RM UNIT MOTOR DRIVE Motor Pulley Pitch Diameter 2.4-3.4 (in.) Pulley Factory Setting Full Turns Open FAN DRIVE Pulley Pitch Dia (in.) Pulley Bore (in.) Belt No. — Section 1—A Belt Pitch (in.)
  • Page 29 Table 9C — High-Static Drive Data, 60 Hz — English 40RM UNIT MOTOR DRIVE Motor Pulley Pitch Diameter 3.4-4.4 (in.) Pulley Factory Setting Full Turns Open FAN DRIVE Pulley Pitch Dia (in.) Pulley Bore (in.) Belt No. — Section 1—A Belt Pitch (in.)
  • Page 30 Table 9E — Medium-Static Drive Data, 50 Hz — English 40RM UNIT MOTOR DRIVE Motor Pulley Pitch Diameter 3.4-4.4 (in.) Pulley Factory Setting Full Turns Open FAN DRIVE Pulley Pitch Dia (in.) Pulley Bore (in.) Belt No. — Section 1—A Belt Pitch (in.)
  • Page 31 40RM UNIT MOTOR DRIVE Motor Pulley Pitch Diameter 61.0- (mm) 86.4 Pulley Factory Setting Full Turns Open FAN DRIVE Pulley Pitch Dia (mm) Pulley Bore (mm) 25.4 Belt No. — Section 1—A Belt Pitch (mm) 1024 FAN SPEEDS (r/s) Factory Setting Range 7.8-11.1...
  • Page 32 Table 9I — High-Static Drive Data, 60 Hz — SI 40RM UNIT MOTOR DRIVE Motor Pulley Pitch Diameter 86.4- (mm) 111.8 Pulley Factory Setting Full Turns Open FAN DRIVE Pulley Pitch Dia (mm) Pulley Bore (mm) 25.4 Belt No. — Section 1—A...
  • Page 33 Table 9K — Medium-Static Drive Data, 50 Hz — SI 40RM UNIT MOTOR DRIVE Motor Pulley Pitch Diameter 86.4- (mm) 111.8 Pulley Factory Setting Full Turns Open FAN DRIVE Pulley Pitch Dia (mm) Pulley Bore (mm) 25.4 Belt No. — Section 1—A...
  • Page 34 Table 10A — Fan Performance Data — 0.0-1.2 in. wg ESP — English AIRFLOW UNIT (Cfm) 1,800 0.22 2,100 0.31 40RM 2,400 0.42 2,700 0.54 3,000 0.69 2,250 0.32 40RM 2,600 0.45 40RMQ 3,000 0.62 40RMS 3,400 0.82 3,750 1.03 2,550 0.42...
  • Page 35 Table 10B — Fan Performance Data — 1.4-2.4 in. wg ESP — English AIRFLOW UNIT (Cfm) 1,800 0.89 2,100 1.02 40RM 2,400 1.16 2,700 1.32 3,000 1.49 2,250 1.06 40RM 2,600 1.22 40RMQ 3,000 1.43 40RMS 3,400 1.66 3,750 1000 1.90...
  • Page 36 filters, and unit casing. See right for factory-supplied filter pres- sure drop. 3. Refer to fan motor and drive tables for additional data. Legend and Notes for Table 10A and 10B Factory-Supplied Filter Pressure Drop — English UNIT 40RM 40RM 40RMQ 40RMS 40RMS 40RM...
  • Page 37 Table 10C — Fan Performance Data — 0-300 Pa ESP — SI AIRFLOW UNIT (L/s) 5.34 0.17 1000 6.28 0.24 40RM 1150 7.22 0.33 1300 8.17 0.43 1450 9.11 0.55 1000 5.63 0.22 40RM 1200 6.76 0.32 40RMQ 1400 7.89 0.46...
  • Page 38 Table 10D — Fan Performance Data — 350-600 Pa ESP — SI AIRFLOW UNIT (L/s) 14.10 0.67 1000 14.60 0.77 40RM 1150 15.10 0.88 1300 15.60 1.01 1450 16.10 1.15 1000 14.30 0.76 40RM 1200 14.80 0.90 40RMQ 1400 15.40 1.06...
  • Page 39: Replacing Filters

    filters, and unit casing. See right for factory-supplied filter pres- sure drop. 3. Refer to fan motor and drive tables for additional data. Factory-Supplied Filter Pressure Drop — SI AIRFLOW PRESSURE DROP UNIT (L/s) 40RM 1150 1450 40RM 1000 40RMQ 1400 40RMS...
  • Page 42 Copyright 1995 Carrier Corporation Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations. Book 1 4 PC 111 Catalog No. 534-053 Printed in U.S.A. Form 40RM-9SI Pg 42 11-95...
  • Page 43 (SPLIT SYSTEMS WITH 40RM/RMQ/RMS UNITS) A. Preliminary Information OUTDOOR: MODEL NO. INDOOR: MODEL NO. ADDITIONAL ACCESSORIES B. Pre-Start-Up OUTDOOR UNIT IS THERE ANY SHIPPING DAMAGE? IF SO, WHERE: WILL THIS DAMAGE PREVENT UNIT START-UP? CHECK POWER SUPPLY. DOES IT AGREE WITH UNIT?
  • Page 44 OIL LEVEL AT ⁄ ⁄ FULL? NOTES: Copyright 1995 Carrier Corporation Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations. Book 1 4 PC 111 Catalog No. 534-053 3c 2e...
