ACCESSORIES AND HARDWARE
INSTALLATION
Mounting Bracket
(Half Sleeve) X1
Removable Trim Ring
INSTALLATION
1. BEFORE INSTALLATION
When mounting the unit in a car, keep the unit as level as possible.
If the unit must be mounted at an angle, due to the design of the vehicle, make sure the unit does
not tilt by more than 30
Mounting Strap
and Screw X4
Unlock Levers
X1
0
.
Remote IR Sensor
X2
23
Locking Screw
X1
