- Page 1 Professional Rewireable Floodlight LEDPRO70B Black LEDPRO70WH White LEDPRO100B Black LEDPRO100WH White...
-
Page 2: General Information
-20°C to +40°C • IP65 Rated, suitable for restricted external applications • Dimensions (H x W x D): 235 x 305 x 66mm • CE Compliant LEDPRO70B & LEDPRO70WH • 70W LED Non replaceable lamp • Energy Usage: 70kWh/1000h • Lumen Output: Black = 7000lm, White = 7100lm LEDPRO100B &... - Page 3 4. Installation • Ensure the mains supply is switched off and the circuit supply fuses are removed or the circuit breaker turned off. • An isolating switch should be installed to enable the power to be switched ON and OFF to the floodlight. This allows the unit to be easily switched OFF for maintenance purposes.
- Page 4 • Fix the U bracket to the wall using the correct screws for the wall plugs being used. Note: Ensure that when you mount this, the slots at the end of the bracket open upwards to allow you to easily attach and secure the floodlight when ready. •...
- Page 5 • Pass the supply cable through the holes(s) provided in the backplate ensuring that a cable gland, grommet or sealing compound is used to maintain the IP rating of the floodlight. • Terminate the supply cable into the terminal block (see section 5. Connection diagram) ensuring correct polarity is observed and that all bare conductors are sleeved.
- Page 6 Live Supply (Brown or Red) to Neutral Supply (Blue or Black) to Earth (Green/Yellow) to Note: the L1 terminal is a Switch Live “Live Output” for slave floodlights (when used in conjunction with the Timeguard LEDPROSLB-WH, LEDPRORFKB-WH PIRs or the LEDPROPCB-WH Photocell).
-
Page 7: Lamp Adjustment
Note: A proof of purchase is required in all cases. For all eligible replacements (where agreed by Timeguard) the customer is responsible for all shipping/postage charges outside of the UK. All shipping costs are to be paid in advance before... - Page 8 If you experience problems, do not immediately return the unit to the store. Telephone the Timeguard Customer Helpline: HELPLINE 020 8450 0515 or email helpline @ timeguard.com Qualified Customer Support Coordinators will be online to assist in resolving your query.
