2. MONITORING STATION SET

2.1.

SV 279 PRO standard set and optional elements

The SV 279 PRO station consists of two
carrying cases. The main case is waterproof
with an internal 17 Ah battery and internal
charging unit supporting powering from
external DC or a solar panel. The SVAN 979
Class 1 sound level meter is installed inside,
but can be removed and used as a hand-held
meter.
All accessories fit conveniently into a second
carrying case.
The SV 279 PRO station includes:
• outdoor microphone kit (1),
• waterproof case with battery,
charging unit and connectors (2),
• controller (3),
• SVAN 979 – Class 1 Sound Level
Meter and Analyser (4),
• 3G modem (5),
• power supply (6).
The waterproof case is equipped with:
• external power connector (7),
• SP274 meteo module connector (8),
• air pressure compensation valve (9)
• input signal connector (10).
Monitoring Station SV 279 PRO
10 9
6
1
2
3
4
5
6
8 7
