Svantek SV 279 PRO User Manual page 10

To connect the cable to the case socket, start by
lining up the key on the plug and socket, then lock
the connector by turning the ring clockwise (only
the ring close to the socket will rotate).
To disconnect cables, push the connector towards
the station and turn it counter-clockwise. New
connectors require more force so using a closed
hand is more effective than using only fingers.
The station is equipped with a Lead-Acid
rechargeable battery (17Ah, 12V), located in the
bottom of the case.
The battery can be used in any chosen position
without the risk of leakage. The battery has a
pressure relief valves that allows safe dispersal of
any excess pressure inside the cell (VRLA).
Battery capacity may vary depending on the
ambient temperature.
The safety fuse is located on the left side of the
connection plate.
Note: Do not remove the battery from the case! This operation must be done
only by the authorised service.
Note: Battery is not restricted for air, surface and water transport. Classified
as non-hazardous material (IATA/ICAO Special Provision A67, DOT-CFR Title 49
parts 171-189, IMDG amendment 27).
Note: It is necessary to charge the battery after any total discharge, otherwise
the battery may lose its capacity.
Note: It is recommended to charge the battery at least every 6 months in the
case of the station not being used.
Monitoring Station SV 279 PRO 10
