- Page 1 OWNERS GUIDE & INSTALLATION INSTRUCTIONS 743 SERIES UNDERBENCH BOILING WATER APPLIANCES...
-
Page 2: Table Of Contents
Rheem Underbench Boiling Water Appliance This manual contains informa on on the installa on, commissioning and opera on of Rheem Underbench Boiling Water Appliances. Models delivering Filtered, Boiling and Ambient or Chilled Water (3‐in‐1) Models delivering Filtered, Boiling, Hot and Ambient or Chilled water (4‐in‐1) Please note that the external design of tapware shown in this manual may differ from that in the package and depends on the model ordered. This does not affect the ... -
Page 3: Important Informa On
Important information Thank you for choosing a Rheem Underbench Boiling Water Appliance. Please take a few minutes to read this manual as it contains important informa on about the correct installa on and opera on of your appliance. This manual applies to Rheem 3‐in‐1 and Rheem 4‐in‐1 Underbench Boiling Water Appliances and Dispensing Taps. If the installa on includes a Rheem Water Chiller, the separate Water Chiller Instruc on Manual should be read in conjunc on with these instruc ons. This appliance is intended to be used in household and similar applica ons such as: – staff kitchen areas in shops, offices and other working environments – farm houses – by clients in hotels, motels and other residen al ‐ type environments – bed and breakfast ‐ type environments. WARNING To ensure the safe opera on of this appliance please observe the following;... -
Page 4: Installa On Requirements
Installation requirements Services required Electrical: 10A earthed 3 pin Socket Outlet sited in the cupboard where the appliance will be installed. NOTE: Where a Rheem Chiller is installed, the Underbench Boiling Water Appliance supplies power to the chiller. The combined maximum current drawn is not more than 10 amp. If a third‐party chiller is installed, an ... -
Page 5: Installing The Dispensing Tap
Installing the Dispensing Tap The design of the Dispensing Tap will vary depending on the model purchased. The tap must be posi oned on the Base Ring benchtop with the outlet over a sink. O‐Ring All Dispensing Taps are mounted through a Ø35mm hole drilled in the benchtop. Bench hole Ø35mm Before ... -
Page 6: Installing The Mixing Tap
AS/NZS 3500.1 specifies a maximum sta c pressure within buildings of 500 kPa at any outlet and notes that pressures above 500 kPa can cause damage from water hammer, reduce the life of appliances, taps and fi ngs, and cause excessive noise in the system. Bench max 50mm Rheem recommends the installa on of a 500 kPa pressure limi ng valve in the supply to the mixing tap if the sta c supply pressure is greater than 500 kPa. Washer clearence Ø52mm Flush out all pipe work prior to installa on. Do not kink or twist flexible connectors. - Page 7 Installing the Mixing Tap Cold Water Supply Isola on Valve Connect BLUE HOSE from Mixing Tap to Inlet Water to Appliance. cold water supply Base Ring Connect PLAIN HOSE to union marked O‐Ring SUPPLY INLET Fixing Stud Washer Clamp Plate Clamp Nut Connect RED HOSE from mixing tap Connect BLACK HOSE to union marked from mixing tap MIXER RED HOSE to union marked MIXER BLACK HOSE IMPORTANT The three flexible hoses must be connected to the correct ports on the mixer. Connect BLACK hose to port marked BLK Connect BLUE hose to port marked BLUE Connect RED hose to port marked RED Screw the flexible hoses into threaded ports in the base of the mixer body un l bo omed ensuring the o‐ring seal is not cut.
-
Page 8: Installing The Underbench Appliance
Installing the Underbench Appliance Tapware Mixing Tap The design of the tapware supplied depends on the model ordered. The illustra ons show the required connec ons Dispensing Tap and are common to all tapware designs. Where no Mixing Tap is to be installed (3‐in‐1 models) there will be no Mixing Tap connec ons on the appliance. Pipe Adaptor Fi ng Ventilation Where no chiller is installed, the cupboard doors must be kept ajar to increase ven la on to the appliance. -
Page 9: Commissioning
Water Chillers • The green light on the Dispensing Tap will flash and the Timer will display the Where a Rheem Chiller is installed the chiller power is supplied from calibra on message. the Boiling Water Appliance and the chiller signal connec on allows • When calibra on is complete the Timer ... -
Page 10: Se Ng Up The Timer
Sleep mode will shut the system down a er a user specified me of no use. The appliance will wake from sleep mode automa cally when a user operates the Dispensing Tap or pushes a bu on on the Timer. If a Rheem Chiller is installed, the opera on of the chiller will be managed by the Timer. The Timer also provides access to various service func ons explained below. - Page 11 Setting Timer ON/OFF Times Service Menu Clock is 24hr me. Through the service menu, various opera onal parameters can be viewed and set. Should error Se ng an iden cal ON/OFF me will make the appliance condi ons arise they can be displayed to assist service ac ve for 24 hrs. technicians. Prog => Set ON/OFF mes => Accept Prog => Service => Accept Display Shows: SUN 7:00 7:00 Set ON hour Press UP to cycle through sub menu.
- Page 12 Selec ng ON displays the current boiling water and Set boiling water delivery me. chilled water temperatures on the main screen. Prog => Hot Tap Time => Accept Up => Temp Show ON/OFF => Accept Display Shows: xx s Display Shows: OFF Press Up Press Up to select me. Display Shows: ON Se able Range 5 to 20 seconds. Note: Chilled water temperature is only displayed when a Rheem Chiller is connected. Key Lock TB Treq When enabled bu ons are locked and user cannot make selec ons. Display boiling water calibra on temperature. Prog => Key Lock => Accept Up => TB Treq => Accept Display Shows: Key Lock Enable Display Shows: TB xx ° C Treq xx ° C Press Accept to enable key lock To ...
-
Page 13: Opera Ng The Appliance
Children should be supervised to ensure they do not interfere with the Boiling Water Appliance. Rheem recommends the use of the Dispensing Tap safety func on, allowing only two‐finger opera on. -
Page 14: Using The Dispensing Tap
Using the Dispensing Tap Tap design will depend on model ordered. Regardless of the model, func on is as illustrated below. Water is delivered on the opera on of the levers: • The boiling water lever has a RED indicator • The cold water lever has a BLUE indicator. Push and hold the lever down To ac vate safety func on, for quick cup fills. push and hold for five seconds un l the RED safety indicators are lit. Aqua™ tap Pull the lever up un l it latches to allow for hands‐free filling. Azure™ tap Safety Lock When ac vated, boiling water can only be delivered when the safety bu on is held down while the hot lever is operated. To ac vate and de‐ac vate the bu on, press and hold it for five seconds. When the safety lock is ac vated, the RED safety indicators on the safety bu on will be lit. Tap Indicators There are two status indicators fi... -
Page 15: Filter Replacement
• Once flushing is complete, reconnect the Filtered Water pipe to the chiller. • If a Rheem Chiller is installed, switch off power and reconnect the electrical connec ons from the Chiller to the Boiling Water Appliance. • Check Appliance is func oning correctly ... -
Page 16: Save A Service Call
STD mode, con nuous Are all Tap LEDs flashing? 24/7 opera on. If the ba ery needs replacing, contact your nearest Rheem Service Centre. Reset the Tap levers to the off posi on. If the LED’s con nue flashing, a fault has occurred with the Tap. Contact Rheem Service to arrange for an inspec on. IF YOU HAVE CHECKED ALL THE ABOVE AND STILL BELIEVE YOU NEED ASSISTANCE, CALL YOUR NEAREST RHEEM SERVICE CENTRE. -
Page 17: Specifica Ons
Specifications Dispensing Taps Azure Tap Aqua Tap Model Code: 319044 Model Code: 319032 Mixing Taps Mixing Tap Model Code: 319119 Mixing Tap Model Code: 319120... -
Page 18: Water Supplies
Water Supplies Chloride and pH Your Boiling Water Appliance is manufactured to suit the water condi ons of most Australian and New Zealand In a high chloride water supply, the water can corrode metropolitan water supplies. However, there are some stainless steel parts and cause them to fail. Where the known water supplies which can have detrimental effects on ... -
Page 19: Rheem Warranty
2.5 This warranty only applies to the original and genuine Boiling Water Appliance in its original installed location and any genuine Rheem replacement parts. 2.6 If the Boiling Water Appliance is not sized to supply the hot water demand in accordance with the guidelines in Rheem’s Boiling Water Appliance literature, any resultant fault will not be covered by Rheem's warranty. - Page 20 RHEEM WARRANTY Boiling Water Appliance Warranty New Zealand & Australia 3. WHAT IS COVERED BY THIS RHEEM WARRANTY 3.1 Rheem will repair or replace a faulty component of your Boiling Water Appliance if it fails to operate in accordance with its specifications as follows: This Rheem warranty covers residen al, Warranty Cover Warranty Period commercial and industerial installa ons. The period in which the fault What components are covered What coverage you receive must appear in order to be covered New component or replacemant Appliance All Components Years ( at Rheem's sole discre on), (from date of installa on 1 & 2 free of charge, including labour** All installa ons / All models Refer to note below. Where an inner tank fails it will be supplied free of Years Inner Tank Only charge, installa on and labour cost will be charged 3 ‐ 5 to the owner. Note: Refer to items 2.3 and 2.4 of warranty conditions. ENTITLEMENT TO MAKE A CLAIM UNDER THIS WARRANTY 4.1 To be entitled to make a claim under this warranty you need to: ...
- Page 21 Rheem New Zealand Limited Freephone 0800 657 336 Freefax 0800 657 337 Telephone 09 829 0200 475 Rosebank Road, Avondale 1026 PO Box 19011, Avondale, Auckland 1746, New Zealand www.rheem.co.nz Rheem Australia Pty Ltd A.B.N. 21 098 823 511 For Service Telephone 131 031...
