Summary of Contents for Rheem Raypak XFIIRE
- Page 1 Manual Touchscreen & Wi-Fi Firmware Update...
- Page 2 Raymote Firmware Update Before Installation Terminate any active call for heat. Disable the boiler operation in the “boiler” menu or deactivate the enable switch on the unit. Allow the unit to shut down. Turn OFF the boiler main power switch. Make sure the boiler is completely de-energized.
- Page 3 XFIIRE AND XVERS-L...
- Page 4 XFIIRE & XVERS-L SD Card update SD card is located on the back of the In a computer, Download 4.3” update *.zip file from: touchscreen. To gain access to the back of the screen, gently pull the plastic bezel towards you. Raypak.com/raymoteupdate Insert the SD Card in the computer.
- Page 5 XFIIRE & XVERS-L Reinstall SD card in the touchscreen. Touchscreen Software update starts automatically. Wait until software has been installed. DO NOT INTERRUPT POWER Reinstall touchscreen bezel and turn on the unit. Press Next to start WiFi module update DO NOT INTERRUPT POWER...
- Page 6 XFIIRE & XVERS-L WiFi module Flashing starts automatically. Touchscreen reboots after update is completed.
- Page 7 MVB & XTherm...
- Page 8 MVB & XTherm SD Card update SD card is located on the left side of the Remove the j-box cover panel touchscreen. To gain access to the screen, remove the knurled screw that secures the front sheet metal panel. Remove the front panel.
- Page 9 MVB & XTherm Important: Verify if module is new generation, access to Touchscreen back is required. if it is previous generation the Wi- Fi module HW needs to be replaced. Old Generation, needs to be replaced New Generation Call Raypak...
- Page 10 MVB & XTherm Important: Verify if module is new generation, access to Touchscreen back is required. if it is previous generation the Wi-Fi module HW needs to be replaced. Remove the four (4) 5/16” hex screws from the Remove the touchscreen rear cover. touchscreen mounting brackets on the Junction- box.
- Page 11 MVB & XTherm Once module compatibility is verified. Extract SD card by carefully pressing to release. SD card has a spring-lock mechanism. WiFi Module...
- Page 12 MVB & XTherm In a computer, Download 7” update *.zip file from: Reinstall SD card and the back cover in the touchscreen. Raypak.com/raymoteupdate Insert the SD Card in the computer. Locate the downloaded zip file and unzip it directly into the SD card Reinstall the touchscreen SD card content should have...
- Page 13 MVB & XTherm Reinstall the J-box cover. Touchscreen Software update starts automatically. Wait until software has been installed. DO NOT INTERRUPT POWER 13. Reinstall the front panel and turn on the unit. Press Next to start WiFi module update DO NOT INTERRUPT POWER...
- Page 14 MVB & XTherm WiFi module Flashing starts automatically. Touchscreen reboots after update is completed.
- Page 15 XVERS...
- Page 16 XVERS SD Card update SD card is located on the left side of the Remove the 5/16" Phillips screw that secures touchscreen. To gain access to the screen, the swing panel. release the four snap fasteners to remove the font cover panels from the unit.
- Page 17 MVB & XTherm Important: Verify if module is new generation, access to Touchscreen back is required. if it is previous generation the Wi- Fi module HW needs to be replaced. Old Generation, needs to be replaced New Generation Call Raypak...
- Page 18 XVERS Important: Verify if module is new generation, access to Touchscreen back is required. if it is previous generation the Wi-Fi module HW needs to be replaced. Check the WiFi module chip. If the WiFi module is Black, remove the SD Remove the touchscreen rear cover.
- Page 19 XVERS In a computer, Download 7” update *.zip file from: Raypak.com/raymoteupdate Insert the SD Card in the computer. Locate the downloaded zip file and unzip it directly into the SD card SD card content should have \Amulet_msd\...
- Page 20 XVERS Touchscreen Software update starts automatically. Reinstall the SD card and the back cover in the touchscreen. Wait until software has been installed. SD Card DO NOT INTERRUPT POWER Press Next to start WiFi module update Reinstall the swing frame and front panel DO NOT INTERRUPT POWER...
- Page 21 XVERS WiFi module Flashing starts automatically. Touchscreen is reset after update is completed.
-
Page 22: Troubleshooting
Troubleshooting... - Page 23 Verify SD Card Folder Structure 1.- SD Card root directory folder structure must be “Amulet_msd” 2.- Programming file (*.pdb) shall be located here Firmware name Firmware name...
- Page 24 How to verify Wi-Fi Module Firmware 1.- Go to Wi-Fi page on the unit touchscreen 2.- Locate Module SW Rev X.7.0 ssid...
- Page 25 SD card is not recognized Issue: SD Card Corrupted Solution 1.- With SD card inserted into PC Slot, go to Disk Management 2.- Within Disk Management right click on SD card “unallocated space”, and Select “new simple Volume”...
