Intense Cycles TAZER User Manual page 11

1
2
3
r e m o v i n g t h e b a t t e r y //
A Remove battery door by using B Lift the door up at the angle it's
two fingers to compress or pull at, freeing the lower locating tab
the snap lock tab back toward from the frame (Image #3).
the door. This will allow the door
to pivot open so it is now angled C With your right hand, insert
off the downtube (Images #1, #2). battery key into lock.
D With your left hand, unfold and
hold battery pull strap.
2 0 // t a z e r u s e r m a n u a l
4
6
5 7
E Turn battery key a quarter turn H Continue pulling battery pull
with right hand (Image #4). strap with left hand while holding
onto the top of battery with right
F Pull battery strap with left hand hand. The battery will continue to
until the battery has moved past pivot off the lower mount and out
the front lock (Image #5). of the downtube (Image # 6).
G Release the key. The key can I Lift the battery out and away from
now be removed and placed in a the downtube (Image #7).
safe, easy to access location.
1
3
2
i n s t a l l i n g t h e b a t t e r y //
A Place pull strap on battery as into the lower battery mount as the
shown, then lift battery up with top of the battery is pushed toward
two hands, left hand on the pull the upper battery mount (Image #2).
strap and right hand at top of
battery (Image #1). C Continue pushing the top of the
battery so that it slides into the
B Angle the bottom of battery into the upper mount then clicks and locks
lower mount of the downtube and into place.
push it into the lower mount. The
bottom of the battery should now be D Confirm the battery has clicked
hooked into the lower battery mount. and is fully seated in the top
With it hooked it should now pivot battery mount by tugging on the
5
6
4
battery pull strap. If battery moves F Once the battery door fully slides
away from the mount then push it down into the door opening, pivot
back against mount until battery the door in a closing motion
is fully seated (Image #3). The (Image #5) .
battery pull strap can now be
folded onto itself so it doesn't G As the door is nearing the closed
obstruct the battery door. position at the top of the door give
the door a good push to allow the
E Re-install the battery door door's snap lock feature to engage
with the lower tab fitting into the into the downtube (Image #6).
downtube opening first (Image #4).
I N T E N S E C Y C L E S // 2 1
